Assa Abloy Sargent 6-Line Installation Instructions

Bored lock

Installation Instructions

6-Line

Bored Lock

Attention Installer:

these intructions carefully to prevent missing important steps

Please read

Note:

Improper installation may result in damage to lock and void factory warranty

WARNING

This product can expose you to lead which

is known to the state of California to cause

cancer and birth defects or other reproductive

harm. For more information go to www.

P65warnings.ca.gov.

1-800-727-5477 • www.sargentlock.com

part without the express written permission of SARGENT Manufacturing Company is prohibited.

A6286M 4/20

Table of Contents

Need help?

Do you have a question about the Sargent 6-Line and is the answer not in the manual?

Page 1 Installation Instructions 6-Line Bored Lock Attention Installer: these intructions carefully to prevent missing important steps Please read Note: Improper installation may result in damage to lock and void factory warranty WARNING This product can expose you to lead which is known to the state of California to cause cancer and birth defects or other reproductive harm.
Page 2 6 Line Bored Lock Installation Instructions Table of Contents Installation ..............2 Install Latch Unit .
Page 3 6 Line Bored Lock Installation Instructions Installation (continued) Adjust for Door and Thickness • Rotate outside rose in or out, depending on door thickness. Lock will fit any door from 1 3/8 “ to 1 3/4”. Install Lock Unit • Lock unit housing must engage latch unit prongs and retractor must engage latch tailpiece.
Page 4 Installation (continued) If not, reverse cylinder as follows: 1. Insert key fully into cylinder. 2. Press a small nail into the outside knob sleeve hole. 3. Turn key (in clockwise direction) aprox. 45º or until depression of the knob catch is felt with nail; pull off knob.
