Assa Abloy Norton 6000 Series Installation And Instruction Manual

For replacement of 6020LAP on
existing 6020 or 6030 installs,
see page 4.
!
WARNING: Make sure that (120V, 60Hz) input power is turned off at facility's main
IMPORTANT INSTALLATION INSTRUCTIONS
1) READ AND FOLLOW ALL INSTALLATION
INSTRUCTIONS.
2) Install only on a properly operating and balanced door. A
door that is operating improperly could cause severe
injury. Have qualified service personnel make repairs to
any hardware before installing the operator.
WARNING: To reduce the risk of injury to person,
use this operator only with Pedestrian Swing doors.
For Indoor Use Only.
Copyright © 2017 Yale Security Inc., an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written permission of Yale Security Inc. is prohibited.
Installation and Instruction Manual
circuit breaker before proceeding with installation.
6010LAP / 6020LAP Replacement
For replacement of 6010LAP on
existing 6010 or 6050 installs,
see page 2.
For replacement of 6020LAP on
existing 6060 or 6070 installs,
see page 6.
3) Remove, or make inoperative, all locks (unless
mechanically and/or electrically interlocked to the
power unit) that are connected to the door before
installing the operator.
4) Do not connect the door operator to the source
power until instructed to do so.
ETL certified; conforms to ANSI/UL standard
325 for automatic closing doors and UL10C
Positive Pressure Fire Test for Door Assemblies.
Certified to ANSI/BHMA A156.19 for Low Energy
Door Operators.
6000 Series
80-9360-1020-020 Rev 1 02/17
