  • Page 1 COMPLI 1535/2 B2 HL 1555/2 B2 HL 1575/2 B5 HL 15100/2 B5 HL 15200/2 B6 HL 1525/4 C1 HL 1535/4 C1 HL 1555/4 C5 HL 1575/4 C5 HL 1575/4 B6 HL COMPLI 2535/2 B2 HL 2555/2 B2 HL 2575/2 B5 HL 25100/2 B5 HL 25200/2 B6 HL 2525/4 C1 HL...

  • Page 2: Safety Instructions

    ENGLISH You have purchased a product made by Pentair Jung Pum- the equipment is installed and put into operation. The manual must always be available at the location where the pump or the pen and with it, therefore, also excellent quality and service. plant is installed.

  • Page 3: Installation

    ENGLISH Never work alone. Always wear a hard hat, safety glasses and Supply package safety shoes and, if necessary, a suitable safety belt. • One or two tanks with a DN 150 inlet clamping flange Before carrying out welding works or using electrical devices, •...
  • Page 4 ENGLISH Screw three duckfeet to the underside of each bend. Connecting the pumps Connect the bends to the tank using a flexible connector and The pumps are connected to the control unit on site in ac- hose clamps. cordance with the circuit diagram (appendix). The three-phase pumps are protected with an overcurrent release or motor Next, bolt the bends to the floor.

  • Page 5: Operation

    ENGLISH Test run and functional check the existing operating mode is highlighted as a negative image. NOTICE! First of all tighten all clamps and flanged connections. MANUAL/ON The pump continues to run in manual mode until a different 1. Open the maintenance cover on the tank. operating mode is selected.
  • Page 6 ENGLISH • Operating hours OPERATION Displays the operating hours per pump and the pump switching cycles • Event memory Shows the error messages of the system. The newest mes- sage is at the top, older ones below. After 70 messages, the oldest message is deleted from the memory.

  • Page 7: Level Control

    ENGLISH continuously for longer than the time specified here, an alarm SETTINGS will be triggered. The maximum runtime monitoring is only active in ATEX mode and can be reset after it has been triggered by the acknowl- edgement button. If the acknowledgement button is not pressed, an automatic reset occurs at the S2 time after 7 times the triggering time and at the S3 time triggering after the S3 pause time.
  • Page 8 ENGLISH Delay alarm simulated time-current characteristic of the motor protection relay. NOTE! No alarm delay is available in 9V battery operation. In order not to trigger an alarm immediately with short-term Maintenance events, a delay can be set for the switching of the alarm con- tacts.

  • Page 9: Error Messages

    ENGLISH Overcurrent. If the measured motor current (current trans- Display contrast former measurement on the board) is above the entered maxi- mum motor current, the pump is switched off depending on The contrast can be changed using the bar display. a simulated time-current characteristic of the motor protec- tion relay.

  • Page 10: Oil Check

    ENGLISH 10. In addition, clean the float if necessary. QUICK TIPS FOR REMEDYING FAULTS When all the servicing tasks have been performed, carry out a test run and then put the unit back into operation. The service must be documented, giving details of the important data and WARNING! of all the tasks carried out.

  • Page 11: Technical Data

    ENGLISH TECHNICAL DATA Weight depending on type 4-6 kg Protection category IP 44 Operating voltage 3/N/PE x 400 V, 50 Hz Power consumption of control unit approx. 8 W Control fuse F1 fine-wire fuse 5x20 mm, 6.3 A T/MT; EN 60127-2-5, DIN 41571-2 Fuse alternating current output F2 fine-wire fuse 5x20 mm, 2.0 A T/MT;...

  • Page 12: Further Settings

    ENGLISH Parameter Factory default setting Client setting Level detection Level detection Compli base load ON depending on analogue level detection Base load OFF depending on analogue level detection peak load ON depending on analogue level detection Peak load OFF depending on analogue level detection High water depending on analogue level detection Upper edge of pump...

  • Page 13: Email Settings

    ENGLISH Parameter Factory default setting Client setting Communication SIM card PIN no. Cell phone provider APN.com Authentication User name Password Receiver SMS1 Receiver SMS2 Receiver SMS3 SMS acknowledgement SMS response time 5 minutes Routine messages 10 days at 8:00 Additional call for SMS Station ID SGJU4 Station name...
  • Page 15 Compli 1500...
  • Page 16 Compli 2500...
  • Page 17 Compli Sensor...
  • Page 18 HighLogo 2-00 P - 2-610 P -- 1 --...
  • Page 19 HighLogo 2-00 P - 2-610 P -- 2 --...
  • Page 20 HighLogo 2-610 ECP -- 1 --...
  • Page 21 HighLogo 2-610 ECP -- 2 --...
  • Page 22 HighLogo 2-610 PD -- 1 --...
  • Page 23 HighLogo 2-610 PD -- 2 --...
  • Page 24 HighLogo 5-1016 P - 5-1620 P -- 1 --...
  • Page 25 HighLogo 5-1016 P - 5-1620 P -- 2 --...
  • Page 26 HighLogo 5-2532 P -- 1 --...
  • Page 27 HighLogo 5-2532 P -- 2 --...
  • Page 28 1235/2 BW HL (JP50122) compli 1575/4 B6 HL (JP50127) compli 2575/4 B6 HL (JP50137) compli 1035/2 BW HL (JP50110) compli 1535/2 B2 HL (JP50128) compli 2535/2 B2 HL (JP50138) compli 1555/2 B2 HL (JP50129) compli 2555/2 B2 HL (JP50139)
  • Page 29 Compli 1210/4 E HL GB (JP50170) Compli 1575/4 B6 HL (JP50745) Compli 2555/4 C5 HL (JP50753) Compli 1215/4 BW HL (JP50736) Compli 1535/2 B2 HL (JP50746) Compli 2575/4 C5 HL (JP50754) Compli 1225/4 BW HL (JP50738) Compli 1555/2 B2 HL (JP50747)
  • Page 30 Compli 1575/4 C5 HL Compli 1575/4 C5 HL (JP50126) (JP50744) Compli 1575/4 B6 HL Compli 1575/4 B6 HL (JP50127) (JP50745) Compli 1535/2 B2 HL Compli 1535/2 B2 HL (JP50128) (JP50746) Compli 1555/2 B2 HL Compli 1555/2 B2 HL (JP50129) (JP50747)
  • Page 31 Compli 1575/4 C5 HL Compli 1575/4 C5 HL (JP50126) (JP50126) Compli 1575/4 B6 HL Compli 1575/4 B6 HL (JP50127) (JP50127) Compli 1535/2 B2 HL Compli 1535/2 B2 HL (JP50128) (JP50128) Compli 1555/2 B2 HL Compli 1555/2 B2 HL (JP50129) (JP50129)
  • Page 32 Compli 1575/4 C5 HL Compli 1575/4 C5 HL (JP50126) (JP50126) Compli 1575/4 B6 HL Compli 1575/4 B6 HL (JP50127) (JP50127) Compli 1535/2 B2 HL Compli 1535/2 B2 HL (JP50128) (JP50128) Compli 1555/2 B2 HL Compli 1555/2 B2 HL (JP50129) (JP50129)
