Operation and Maintenance Manual
Efflu Maxi 120 Twin - Compli 1200 HL
1010/4 BWE HL
1010/4 BW HL
1015/4 BW HL
1210/4 BW HL
1215/4 BW HL
Pump Technology Ltd. UK Authorised Distributor for Jung Pumpen GmbH t: 0118 9821 555 w: www.pumptechnology.co.uk
1025/4 BW HL
1025/2 BW HL
1225/4 BW HL
1225/2 BW HL
1035/2 BW HL
1235/2 BW HL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pentair Jung Pumpen Efflu Maxi 120 Twin
Summary of Contents for Pentair Jung Pumpen Efflu Maxi 120 Twin
- Page 1 Operation and Maintenance Manual Efflu Maxi 120 Twin - Compli 1200 HL 1010/4 BWE HL 1010/4 BW HL 1015/4 BW HL 1025/4 BW HL 1025/2 BW HL 1035/2 BW HL 1210/4 BW HL 1215/4 BW HL 1225/4 BW HL 1225/2 BW HL 1235/2 BW HL Pump Technology Ltd.
- Page 2 You have purchased a product made by Pentair Jung Pum- SAFETY INSTRUCTIONS pen and with it, therefore, also excellent quality and service. Secure this service by carrying out the installation works This instruction manual contains essential information that in accordance with the instructions, so that our product must be observed during installation, operation and servic- ing.
- Page 3 Unauthorised operating methods • Safety in wastewater systems (e.g., GUV-V C5, GUV-R 104 and GUV-R 126 in Germany) The operational safety of the supplied equipment is only guar- • Electrical systems and operating resources (e.g., GUV-V A3 anteed if the equipment is used for its intended purpose. The in Germany) limiting values given in the "Technical Data"...
- Page 4 Installing the tank Installing the control unit Close the sluice valve in the inlet (accessory) to prevent any NOTICE! Only qualified electricians may carry out electrical leakage of water during the installation work. works to the pump or the controls. Units must be slid onto the inlet pipe, together with the clamp NOTICE! Never put the mains plug or open cable end in water! flange, as far as possible and then aligned.
- Page 5 Switching levels OPERATION The switch-on and switch-off points are set ex works for the standard inlet height of the respective system. In exceptional cases, however, they can be changed under the menu item "Level control". Alarm relays Display As alarm outputs, a potential-loaded alarm relay (protected by internal control fuse F2) and a potential-free changeover con- LED pump 1 and pump 2 tact are available.
- Page 6 INFORMATION WARNING! For repair and maintenance work on pumps or control units, do not use the "Off" function, but always de-energize the system by unscrewing the back-up fuses or via a main switch and se- cure against being switched on again! NOTICE! If unusually large quantities of wastewater flow into the unit (e.g.
-
Page 7: P1 [Kw]
• AUX logic Level Control Shows whether the auxiliary input works as an NC contact or an NO contact The different types can be selected here. The switching levels for the various lifting stations are already pre-set. In excep- • AUX influence tional cases, however, they can be changed under this menu Shows, what influence the auxiliary input as on the pumps item. -
Page 8: F [Hz]
Acoustic alarm Options “On” and “Off”. This function is activated as standard and does not need to be If this function is deactivated, only the integrated alarm buzzer deactivated when supplied with AC power. is switched off. Options: Off/on. Buzzer reactivation If a fault is acknowledged, the buzzer stops and the non-isolat- After a buzzer acknowledgement, the alarm is automatically ed relay drops out. - Page 9 Sensor calibration Update For readjustment, fill the container (fill level of the respective Only for calling the manufacturer' s Customer Service. type see appendix) and then select this menu item "Sensor calibration". Balanced working hours Calibration is performed automatically when 20s have elapsed or the OK button is pressed.
- Page 10 • However, if the oil is contaminated with both water and pol- MAINTENANCE lutants, then not only the oil must be replaced, but the me- chanical seal as well. Maintenance and inspection of this product must be carried For monitoring the oil reservoir, it is also possible to retrofit the out in accordance with EN 12056-4.
- Page 11 QUICK TIPS FOR REMEDYING FAULTS WARNING! Before carrying out any work: Disconnect the pump(s) and the control unit from the mains by unscrewing and taking out the pre-fuses, and take action to ensure that no one else can re- connect them to the power supply. NOTE! Work on the control unit must be carried out by qualified electricians only! •...
- Page 12 TECHNICAL DATA Weight depending on type 4-6 kg Protection category IP 44 1/N/PE x 230 V, 50 Hz Operating voltage 3/N/PE x 400 V, 50 Hz Power consumption of control unit approx. 8 W Control fuse F1 fine-wire fuse 5x20 mm, 6.3 A T/MT; EN 60127-2-5, DIN 41571-2 Fuse alternating current output F2 fine-wire fuse 5x20 mm, 2.0 A T/MT;...
- Page 13 Parameter Factory default setting Client setting Level detection Level detection Compli base load ON depending on analogue level detection Base load OFF depending on analogue level detection peak load ON depending on analogue level detection Peak load OFF depending on analogue level detection High water depending on analogue level detection Upper edge of pump...
- Page 14 Communication SIM card PIN no. Cell phone provider APN.com Authentication User name Password Receiver SMS1 Receiver SMS2 Receiver SMS3 SMS acknowledgement SMS response time 5 minutes Routine messages 10 days at 8:00 Additional call for SMS Station ID SGJU4 Station name PENTAIR-HighLogo Error transmission △...
- Page 15 Pump Technology Ltd. UK Authorised Distributor for Jung Pumpen GmbH t: 0118 9821 555 w: www.pumptechnology.co.uk...
- Page 16 Pump Technology Ltd. UK Authorised Distributor for Jung Pumpen GmbH t: 0118 9821 555 w: www.pumptechnology.co.uk Pump Technology Ltd. UK Authorised Distributor for Jung Pumpen GmbH t: 0118 9821 555 w: www.pumptechnology.co.uk...
- Page 17 EU-Konformitätserklärung EU-Déclaration de Conformité EU-Declaração de Conformidade EU-Prohlášeni o shodě EU-Megfelelöségi nyilatkozat EU-Declaraţie de conformitate EU-Overensstemmelseserklæring EU-Dichiarazione di conformità EU-Vyhlásenie o zhode EU-Declaration of Conformity EU-Conformiteitsverklaring EU-Försäkran om överensstämmelse EU-Vaatimustenmukaisuusvakuutus EU-Deklaracja zgodności DE - Richtlinien - Harmonisierte Normen FR - Directives - Normes harmonisées PT –...
- Page 18 UKCA-Declaration of Conformity Legislation - Designated Standards • Supply of Machinery (Safety) Regulations 2008 (MD) EN 809:1998/AC:2010, EN ISO 12100:2010, EN 60335-1:2012/A13:2017 • The Restriction of the Use of Certain Hazardous Substance in Electrical and Electronic Equipment Regulations 2012 (RoHS) •...
-
Page 19: Table Of Contents
Technische Daten - Technical data - Caractéristiques techniques - Technische Ge- gevens - Dati tecnici - Dane techniczne ... 1010/4 BWE ... 1010/4 BW ... 1015/4 BW ... 1025/4 BW ... 1025/2 BW ... 1035/2 BW ... 1210/4 BW ... 1215/4 BW ... - Page 20 Compli 1000 Compli 1200 Pump Technology Ltd. UK Authorised Distributor for Jung Pumpen GmbH t: 0118 9821 555 w: www.pumptechnology.co.uk...
- Page 21 Compli Sensor Pump Technology Ltd. UK Authorised Distributor for Jung Pumpen GmbH t: 0118 9821 555 w: www.pumptechnology.co.uk...
- Page 22 HighLogo 2-610 ECP -- 1 -- Pump Technology Ltd. UK Authorised Distributor for Jung Pumpen GmbH t: 0118 9821 555 w: www.pumptechnology.co.uk...
- Page 23 HighLogo 2-610 ECP -- 2 -- Pump Technology Ltd. UK Authorised Distributor for Jung Pumpen GmbH t: 0118 9821 555 w: www.pumptechnology.co.uk...
- Page 24 HighLogo 2-00 P - 2-610 P -- 1 -- Pump Technology Ltd. UK Authorised Distributor for Jung Pumpen GmbH t: 0118 9821 555 w: www.pumptechnology.co.uk...
- Page 25 HighLogo 2-00 P - 2-610 P -- 2 -- Pump Technology Ltd. UK Authorised Distributor for Jung Pumpen GmbH t: 0118 9821 555 w: www.pumptechnology.co.uk...
- Page 26 RG7 4PW CONTACT US Telephone: 0118 982 1555 Fax: 0118 982 1666 Email: support@pumptechnology.co.uk Pump Technology Ltd. UK Authorised Distributor for Jung Pumpen GmbH t: 0118 9821 555 w: www.pumptechnology.co.uk Efflu Maxi 120 Twin Compli O&M Manual rev 1 22.03.2023...
