EVAL-M1-05F310 User Manual
iMOTION™ Modular Application Design Kit
Main features
3.1

Key data

Figure 2 provides the overview of the IRSM005-301MH internal electrical schematics. For further information
regarding these CIPOS™ like static and dynamic electrical behavior, as well as thermal and mechanical
characteristics please refer to the datasheet of the IRSM005-301MH.
Figure 2 CIPOS™ Nano internal electrical schematic
Table 2 Provide the absolute maximum ratings of the IRSM005-301MH.
Table 2 Absolute Maximum Ratings of IRSM005-301MH
Symbol Description
V MOSFET Drain-to-Source Voltage
DS
I Maximum DC Current per MOSFET @ T
O
(Note1)
Maximum Power Dissipation per
P
d
MOSFET@ T
T (MOSFET Operating Junction Temperature
J
& IC)
T Storage Temperature range
S
V High Side Floating Supply Voltage
B
V High Side Floating Supply Offset Voltage
S
V Low Side Fixed Supply voltage
CC
V Low Input Voltage of LIN, HIN
IN
Note 1：Calculated based on maximum junction temperature. Bond wires current limit is 20A.
User Manual
=100°C
C
Min
--
--
=25°C
C
--
--
-40
-0.3
VB-20
-0.3
-0.3
6
Max Unit
100 V
30 A
13.5 W
150 °C
150 °C
VS+20 V
VB+0.3 V
20 V
VCC+0.3V V
