Owner's Manual
Original Instructions
Commercial Air Conditioners
Mini Chiller
Models:
HLR8Pd/Na-K
HLR10Pd/Na-K
HLR12Pd/Na-M
HLR14Pd/Na-M
Thank you for choosing commercial air conditioners. Please read
this Owner' s Manual carefully before operation and retain it for
future reference.
If you have lost the Owner's Manual,please contact the local agent
or visit www.gree.com or send an email to global@gree.com.cn for
the electronic version.
GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI
eries

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVO S Series and is the answer not in the manual?

Questions and answers

Related Manuals for Gree EVO S Series

Summary of Contents for Gree EVO S Series

  • Page 1 Owner’ s Manual carefully before operation and retain it for future reference. If you have lost the Owner's Manual,please contact the local agent or visit www.gree.com or send an email to global@gree.com.cn for the electronic version. GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI...
  • Page 2 (6) The final right to interpret for this instruction manual belongs to Gree Electric Appliances Inc. of Zhuhai.

  • Page 3: Table Of Contents

    Contents Safety Notices (Please be sure to abide) ..............1 1 Instruction to Users....................4 2 Safety Considerations....................5 3 Diagram of the Operating Principle ................8 4 Operating Principle of the Unit .................. 8 5 Nomenclature......................9 6 Installation Example ....................10 7 Main Components ....................

  • Page 4: Safety Notices (Please Be Sure To Abide)

    eries Mini Chiller Safety Notices (Please be sure to abide) WARNING: If not abide strictly, it may cause severe damage to the unit or the people. NOTE: If not abide strictly, it may cause slight or medium damage to the unit or the people.
  • Page 5 • Do not use or place inflammable or explosive substances near the unit. • Do not do troubleshooting personally, as incorrect troubleshooting would lead to electrocution or fire hazards. Instead, please contact GREE after-sales service center. CAUTION • Do not let the unit out of the designed application range; otherwise it would cause the heat exchanging tube cracking, refrigerant leakage or even explosion.
  • Page 6 eries Mini Chiller • Do operate the unit in accordance with this manual and read it carefully before startup or troubleshooting. • Do not let children pull power lines or climb the unit to prevent of electrocution or other dangers. ...

  • Page 7: Instruction To Users

    eries Mini Chiller 1 Instruction to Users Thank you for choosing our mini chillers. Please read this manual carefully before installation and use the unit correctly according to the following procedure. (1) After receipt of the unit, check it for appearance, unit model compared with your desire and attachments. (2) For proper installation and future maintenance please read this Instruction and keep it carefully.

  • Page 8: Safety Considerations

    eries Mini Chiller 2 Safety Considerations Please read the following contents carefully before operating. WARNING ■ Once abnormality like burning ■ Don't operate the unit with ■ Before installation,please smell occurs, please cut off wet hands. see if the voltage of local the power supply immediately place accords with that and then contact with service...
  • Page 9 eries Mini Chiller ■ Earthing: the unit must be ■ Never insert any foreign ■ Don't attempt to repair earthed reliably ! The earthing matter into uint to avoid the unit by yourself. wire should connect with damage . And never insert special device of buildings.
  • Page 10 eries Mini Chiller NOTE • Before installation, please check if the adopted power is accordance with that listed on nameplate, and check the safety of power. • Before using, please check and confirm if wires and water pipes are connected correctly to avid water leakage, electric shock or fire etc.

  • Page 11: Diagram Of The Operating Principle

    eries Mini Chiller 3 Diagram of the Operating Principle Field Supplied Monobloc Unit 21 22 Name Name Name Name Inverter compressor EXV 1 Expansion tank 2-way valve Discharge temperature Flasher Safety valve Floor radiator sensor High-pressure switch Pressure sensor Flow switch Water collector High pressure sensor Solenoid valve...

  • Page 12: Nomenclature

    eries Mini Chiller Cooling: in cooling mode, refrigerant is condensed in the aluminum fin-copper tube and evaporated in the plate heat exchanger. Via heat exchange with water in the plate heat exchanger, the temperature of water decreases and it releases heat while the refrigerant absorbs heat and evaporates. With the help of the wired controller, the outflow temperature can meet the user’s requirement.

  • Page 13: Installation Example

    eries Mini Chiller Model Line-Up Capacity Model Name Power supply Heating Cooling HLR8Pd/Na-K 220-240V,1Ph,50Hz HLR10Pd/Na-K HLR12Pd/Na-M 380-415V,3Ph,50Hz HLR14Pd/Na-M Notes: Capacities and power inputs are based on the following conditions: Indoor Water Temperature 40°C/45°C,Outdoor Air Temperature 7°C DB/6°C WB; Capacities and power inputs are based on the following conditions: Indoor Water Temperature 12°C/7°C,Outdoor Air Temperature 35°C DB/-.
  • Page 14 eries Mini Chiller The tank-type electric heater and AC contacts should be selected according to the selection instructions and the thermostat and its upper limit should be decided by the protection function of the electric heater. In order to ensure product quality and service life, it is unallowable to do wiring directly at the main board by the user themselves to prevent the main board from being damaged.
  • Page 15 eries Mini Chiller Field Installation Diagramof the Electric Heater (with the thermostat) Electric Box 4T26 Main Board AP1 Wiring Board AC Contactor 1 CN26 CN27 Tank-type Electric Heater 4T26 Sensing probe Thermostat AC Contactor 2 Neutral Line (2) See the following statement for installation of two groups of auxiliary electric heaters, including wiring of the AC contactors and the tank-type electric heater.

  • Page 16: Main Components

    eries Mini Chiller Field Instalaltion Diagram of the Electric Heater (without the thermostat) Electric Box 4T26 Mainboard AP1 Wiring Board AC Contactor 1 CN26 CN27 4T26 AC Contactor 2 Notes: (a) During installation, the electric heater should be supplied with three-phase power separately. When only one group of the electric heater is installed, please follow the wiring of any group of the diagram shown above.
  • Page 17 eries Mini Chiller Control Box Flow Switch Flow Switch DC Fan Motor Safety Valve Expansion Tank Water Pump   Compressor Plate Heat Exchanger (2) HLR12Pd/Na-M, HLR14Pd/Na-M...

  • Page 18: Installation Guideline Of The Unit

    eries Mini Chiller Control Box DC Fan Motor Expansion Tank Flow Switch Water Pump Compressor or Plate Heat Exchanger 8 Installation Guideline of the Unit 8.1 Instruction to installation (1) Installation of the unit must be in accordance with national and local safety codes. (2) Installation quality will directly affect the normal use of the air conditioner unit.
  • Page 19 eries Mini Chiller 8.2.2 Outline Dimensions of the Monobloc Unit (1) HLR8Pd/Na-K, HLR10Pd/Na-K 1390 (2) HLR12Pd/Na-M, HLR14Pd/Na-M 1390...
  • Page 20 eries Mini Chiller 8.2.3 Space Requirements for Installation 2000 ＞ 8.2.4 Precautions on installation of the Monobloc Unit (1) When moving the monobloc unit, it is necessary to adopt 2 pieces of long enough rope to hand the unit from 4 directions.

  • Page 21: Water Volume And Pump Capacity (With Pump)

    eries Mini Chiller 8.3 Water Volume and Pump Capacity (with pump) /min Note: during operation, the water pump will adjust its output based on the actual load.

  • Page 22: Water Volume And Expansion Vessel Pressure

    eries Mini Chiller 8.4 Water Volume and Expansion Vessel Pressure Maximum total water volume(liter) Notes: (a) The expansion vessel is 10 liter and 1bar pre-pressurized; (b) Total water volume of 280 liter is default; if total water is changed because of installation condition, the pre-pressure should be adjusted to secure proper operation;...

  • Page 23: Remote Air Temperature Sensor

    eries Mini Chiller 9 Remote Air Temperature Sensor Front side Back side Remote Air Temperature Sensor 1.5 Meters Doors Remote Air Environment CN15 Temp sensor Electric box Notes: (a) Distance between the monobloc unit and the remote air temperature senor should be less than 15 meters due to length of the connection cable of remote air temperature sensor;...

  • Page 24: Thermostat

    eries Mini Chiller 10 Thermostat Installation of the thermostat is very similar to that of the remote air temperature sensor. How to Wire Thermostat (1) Uncover the front cover of the monobloc unit and open the control box. (2) Identify the power specification of the thermostat, if it is 230V , find terminal block XT5 as NO.22~24 and block XT6 as NO.33~34;...

  • Page 25: Wired Controller

    eries Mini Chiller 2-Way Valve 1 WARNING • Normal Open type should be connected to wire (ON) and wire (N)for valve closing in cooling mode. • Normal Closed type should be connected to wire (OFF) and wire (N)for valve closing in cooling mode. (ON) : Line signal (for Normal Open type) from PCB to 2-way valve (OFF) : Line signal (for Normal Closed type) from PCB to 2-way valve (N) : Neutral signal from PCB to 2-way valve...

  • Page 26: Gate-Controller

    eries Mini Chiller 14 Gate-controller If there is gate control function,installation guide follow as: (1) HLR8Pd/Na-K, HLR10Pd/Na-K Gate-Controller (2) HLR12Pd/Na-M, HLR14Pd/Na-M Gate-Controller 15 Charging and Discharging of Refrigerant The unit has been charged with refrigerant before delivery. Overcharging or undercharging will cause the compressor to run improperly or be damaged.

  • Page 27: Electric Wiring

    eries Mini Chiller Pressure Meter Connection Pipe Vacuum pump Note: when vacuuming is finished, pressure inside the unit should be kept lower than 80Pa for at least 30 minutes to make sure there is no leak. Either charging valve 1 or charging valve 2 can be used for vacuuming. (3) Charging: when vacuuming is finished and it is certain that there is no leak, charging can be done.

  • Page 28: Specification Of Power Supply Wire And Leakage Switch

    eries Mini Chiller 16.2 Specification of Power Supply Wire and Leakage Switch Power cable specifications and Leakage switch types in the following list are recommended. Minimum Sectional Leakage Minimum Sectional Power Supply Area of Power Supply Switch Area of Earth Wire Model Wire V,Ph,Hz...

  • Page 29: Wring Diagram

    eries Mini Chiller 17 Wring Diagram 17.1 Control Board (1) Main Board (AP2):HLR8Pd/Na-K,HLR10Pd/Na-K,HLR12Pd/Na-M, HLR14Pd/Na-M ENTH AC-N AC-L VA-1 HEAT ENTH-PRESS L-PRESS H-PRESS COM-ESPE2 PWR1 DC-MOTOR0 T-SENSOR3 DC-MOTOR1 T-SENSOR2 Silk Screen Specification AC_N Neutral wire input of power supply AC_L Live wire input of power supply 4-way valve VA-1 E-heater of chassis...
  • Page 30 eries Mini Chiller (2) Main Board (AP1):HLR8Pd/Na-K, HLR10Pd/Na-K, HLR12Pd/Na-M, HLR14Pd/Na-M HEAT1 BAN-HEAT 2V1_ON 2V2_ON 3V1_ON 3V2_ON OTHER_HEAT_ AC-LN RR UNH HEAT2 2V1_OFF 2V2_OFF 3V1_OFF 3V2_OFF OTHER_HEAT_DCOUT 220V OTHER_HEAT_DCIN CN33 COM-OUT TR-IN CN31 INDOOR_PUMP CN18 TR-OUT 2 POOL_PUMP TR-OUT 1 SOLOR_PUMP T-SEN13 SW_INDOOR SW_SOLAR...
  • Page 31 eries Mini Chiller INDOR_PUMP Control and feedback of the water pump for the main unit Feedback of the water pump for the main unit SW_INDOOR CN25 Detection input of water flow switch for indoor SW_POOL CN17 Detection input of water flow switch for pool DOOR_IN CN23 Door detection input...
  • Page 32 eries Mini Chiller (3) Drive Board (AP4):HLR8Pd/Na-K, HLR10Pd/Na-K G - OUT L1 - 2 P-OU T L2-1 DC-BUS 1 PW R L1-1 AC-L COMM L2-2 COMM1 Silk Screen Introduction AC-L Live line input of the drive board Neutral line input of the drive board L1-1 To PFC inductor brown line L1-2...
  • Page 33 eries Mini Chiller (4) Drive Board (AP4):HLR12Pd/Na-M, HLR14Pd/Na-M Silk Screen Introduction COMM Communication interface [1-3.3V, 2-TX, 3-RX, 4-GND] Switch power interface [1-310VDC, 3-GND] Connector to filter L1-F Connector to filter L2-F Connector to filter L3-F Connector to L1-1 OF PFC reactor 1 Connector to L2-1 OF PFC reactor 2 Connector to L3-1 OF PFC reactor 3 Connector to L3-2 of PFC reactor 3...
  • Page 34 eries Mini Chiller (5) Filter Board (AP3): HLR8Pd/Na-K, HLR10Pd/Na-K AC-N AC-L N-OUT1 N-OUT L -OUT Silk Screen Introduction AC-N Neutral line of the power supply for the main unit AC-L Live line of the power supply for the main unit Neutral line output of the filter board (to the drive board) N-OUT Neutral line output of the filter board (to the main board )
  • Page 35 eries Mini Chiller (6) Filter Board (AP3):HLR12Pd/Na-M, HLR14Pd/Na-M Silk Screen Introduction Connector to power supply output line AC-L1 Connector to power supply output line AC-L2 Connector to power supply output line AC-L3 Connector to power supply neutral line AC-N Connector to power supply output line L1-F (drive board L1-F and AC-L) Connector to power supply output line L2-F (drive board L2-F) Connector to power supply output line L3-F (drive board L3-F) Connector to power supply neutral line N-F (mainboard AC-N)

  • Page 36: Electric Wiring

    eries Mini Chiller 17.2 Electric Wiring 17.2.1 Wiring Principle Refer to Section 15.1. 17.2.2 Electric Wiring Design The wiring diagram stuck to the unit always prevails. Wiring diagram: monobloc unit. HLR8Pd/Na-K, HLR10Pd/Na-K ◆ CODE NAME Power Main Board Only For RT6 AC-L Indoor unit Main Board AC-N...
  • Page 37 eries Mini Chiller 17.2.3 Terminal Board (1) HLR8Pd/Na-K, HLR10Pd/Na-K (2) HLR12Pd/Na-M, HLR14Pd/Na-M...

  • Page 38: Commissioning

    eries Mini Chiller 18 Commissioning 18.1 Check before startup For safety of users and unit, the unit must be started up for check before debugging. The procedures are as below: The following items shall be performed by qualified service men. Confirm together with the sales engineer, dealer, installing contractor and customers for the following items finished or to be finished.

  • Page 39: Test Run

    eries Mini Chiller 18.2 Test run Test run is testing whether the unit can run normally via preoperation. If the unit cannot run normally, find and solve problems until the test run is satisfactory. All inspections must meet the requirements before performing the test run.

  • Page 40: Daily Operation And Maintenance

    eries Mini Chiller 19 Daily Operation and Maintenance In order to avoid damage of the unit, all protecting devices in the unit had been set before delivery, so please do not adjust or remove them. For the first startup of the unit or next startup of unit after long-period stop (above 1 day) by cutting off the power, please electrify the unit in advance to preheat the unit for more than 8 hours.
  • Page 41 GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI Add: West Jinji Rd, Qianshan, Zhuhai,Guangdong, China, 519070 Tel: (+86-756) 8522218 Fax: (+86-756) 8669426 E-mail: gree@gree.com.cn www.gree.com...
