D SERIES MODULAR AIR-COOLED
SCROLL CHILLERS SERVICE MANUAL
T1/R410A/50Hz
(GC201307- I )
ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gree D Series

Summary of Contents for Gree D Series

  • Page 1 D SERIES MODULAR AIR-COOLED SCROLL CHILLERS SERVICE MANUAL T1/R410A/50Hz (GC201307- I ) ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...

  • Page 2: Table Of Contents

    CONTENTS PRODUCT ..................... 2 1 LINEUP ........................2 2 NOMENCLATURE ..................... 2 3 FEATURES ........................ 3 4 PRODUCT DATA ....................... 4 5 OPERATION PRINCIPLE ..................6 CONTROL...................... 8 1 OPERATION FLOWCHART ..................8 2 CONTROL LOGIC ....................10 3 CONTROLLER ......................12 NSTALLATION.....................
  • Page 3 D Series Modular Air-cooled Scroll Chillers Service Manual PRODUCT ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...

  • Page 4: Product

    D Series Modular Air-cooled Scroll Chillers Service Manual PRODUCT 1 LINEUP Capacity (kW/Ton) Product Power Series Model Name Refrigerant Appearance Code Supply Cooling Heating LSQWRF65M/NaD-M EL01500500 60/17.06 65/18.48 LSQWRF80M/NaD-M EL01500520 71/20.19 79.5/22.61 R410A LSQWRF130M/NaD-M EL01500510 120/34.12 130/36.97 LSQWRF160M/NaD-M EL01500530 145/41.23 170/48.34...

  • Page 5: Features

    D series modular air-cooled scroll chillers are constructed of one or up to 16 single units which may vary in structure and in cooling capacity.

  • Page 6: Product Data

    D Series Modular Air-cooled Scroll Chillers Service Manual 4 PRODUCT DATA 4.1 Product Data at Rated Condition Heat LSQWRF65M/NaD-M LSQWRF80M/NaD-M LSQWRF130M/NaD-M LSQWRF160M/NaD-M Pump Models Product EL01500500 EL01500520 EL01500510 EL01500530 Code Capacity steps 0-50-100 0-50-100 0-25-50-75-100 0-25-50-75-100 Cooling 17.06 20.19 34.12 41.23...
  • Page 7 Cooling 5~15/41~59 2.5~6/37~43 15~45/59~113 Heating 40~50/104~122 2.5~6/37~43 -15~24/5~75 Note: when the unit is going to operate beyond the working conditions, please contact Gree for consultation. 4.4 Electric Data Compressor Fan Motor Air Switch Model Rated Power Supply MRC Each NRC Each NRC Each Qty.

  • Page 8: Operation Principle

    D Series Modular Air-cooled Scroll Chillers Service Manual 5 OPERATION PRINCIPLE 5.1 Schematic Diagram The low-pressure superheated refrigerant vapor from the evaporator is drawn into the compressor through which the low-pressure vapor is compressed to hi-temperature and hi-pressure refrigerant vapor. Then, the refrigerant vapor passes the condenser and turns to saturated or sub- evaporates by absorbing heat from the second refrigerant and then is drawn into the compressor again.
  • Page 9 D Series Modular Air-cooled Scroll Chillers Service Manual CONTROL ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...

  • Page 10: Control

    D Series Modular Air-cooled Scroll Chillers Service Manual CONTROL 1 OPERATION FLOWCHART 1.1 Cooling Operation Energize the unit ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 11 D Series Modular Air-cooled Scroll Chillers Service Manual 1.2 Heating Operation Energize the unit ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...

  • Page 12: Control Logic

    D Series Modular Air-cooled Scroll Chillers Service Manual 2 CONTROL LOGIC 2.1 Cooling Control 2.1.1 Control to the Compressor (1). “First On, First Off” “First On, First Off”/“First Off, First On” control indicates the numbered compressor which is started/stopped (2). Temperature Drop/Rise Rate Control...
  • Page 13 D Series Modular Air-cooled Scroll Chillers Service Manual pump keeps running. unchanged and the water pump keeps running. 2.3 Freeze Protection through the wired controller, the unit will be protected again freeze. Free protection is factory defaulted to be ON.

  • Page 14: Controller

    3 CONTROLLER 3.1 Wired Controller This wired controller, especially designed for D series modular air-cooled chillers, is capable of controlling and displaying each running parameter of the chiller and being integrated into the remote monitoring system. 3.1.1 Press Buttons and Icons on the Homepage (1).
  • Page 15 D Series Modular Air-cooled Scroll Chillers Service Manual (2). Display Icons on the Homepage Icon Description Time It indicates the current time. Unit name It indicates the unit name. Running mode It indicates the running mode (cooling, heating or manual defrosting)
  • Page 16 D Series Modular Air-cooled Scroll Chillers Service Manual 3.1.2 Menu Structure of Controller ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 17 D Series Modular Air-cooled Scroll Chillers Service Manual 3.2 Setup of Toggle Switches on the Motherboard Four bit toggle switches are used for indicating hardware address (1~16) of modules, with module No. displayed in turn on the panel as Module 1, Module 2, ……, Module 16. Toggle switches 1, 2, 3 and 4 are binary code, with 1 for the lowest bit and 4 for the highest bit.
  • Page 18 D Series Modular Air-cooled Scroll Chillers Service Manual INSTALLATION ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...

  • Page 19: Nstallation

    D Series Modular Air-cooled Scroll Chillers Service Manual NSTALLATION 1 BEFORE INSTALLATION Please check the attached documents for the unit and accessories in accordance with the packing list. Check the unit and accessories for damage Check the refrigerant charge for leakage Check the cleanliness of the water pipes.
  • Page 20 D Series Modular Air-cooled Scroll Chillers Service Manual (2). Graph for the shape and size for LSQWRF130M/NaD-M Unit:mm (3). Graph for the shape and size for LSQWRF160M/NaD-M Unit:mm 1617(Ground bolt 4-M12 ) 1676 1650 2026(Ground bolt 4-M12) 2226 ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...

  • Page 21: Machine Footprint

    D Series Modular Air-cooled Scroll Chillers Service Manual 5 MACHINE FOOTPRINT A minimum spacing of 1m should be left between any two modules for unobstructed air intake and equipment service. Additionally, a minimum of 2m should be kept between the chiller and any barrier. If allowable, it would be better to set up a suncover 3m ahead of the chiller.

  • Page 22: Typical Water Piping Diagram

    D Series Modular Air-cooled Scroll Chillers Service Manual 6 TYPICAL WATER PIPING DIAGRAM ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...

  • Page 23: Freeze Protection

    D Series Modular Air-cooled Scroll Chillers Service Manual 7 FREEZE PROTECTION measures stated below for freeze protection. Under subzero conditions, it is necessary to shut down the chiller installed outdoor and then drain the evaporator completely. Failure of the chilled water flow switch and the anti-freezing temperature sensor will cause the tube When charging or recovering the refrigerant, the evaporator would crack because of frostbite provided the refrigerant pressure inside the evaporator is under 0.71MPa.
  • Page 24 D Series Modular Air-cooled Scroll Chillers Service Manual 8.2 Wiring between Chiller Modules ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 25 D Series Modular Air-cooled Scroll Chillers Service Manual Min. sectional area of the power cable (mm Capability of the Model Power Supply Air Switch(A) Live Line Neutral Line Earth Line LSQWRF65M/NaD-M LSQWRF80M/NaD-M 380-415V,3Ph,50Hz LSQWRF130M/NaD-M LSQWRF160M/NaD-M Notes: a.The specifications of the minimal size of the neural line should be 4mm...
  • Page 26 D Series Modular Air-cooled Scroll Chillers Service Manual (2). LSQWRF80M/NaD-M The diagram is only for reference and the circuit diagram attached on the unit prevails. ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 27 D Series Modular Air-cooled Scroll Chillers Service Manual (3). LSQWRF130M/NaD-M The diagram is only for reference and the circuit diagram attached on the unit prevails ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 28 D Series Modular Air-cooled Scroll Chillers Service Manual (4). LSQWRF160M/NaD-M ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 29 D Series Modular Air-cooled Scroll Chillers Service Manual MAINTENANCE ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...

  • Page 30: Maintenance

    D Series Modular Air-cooled Scroll Chillers Service Manual MAINTENANCE 1 ERROR LIST Error Rated Element Protection Logic High-pressure High pressure switch protection compressor will stop and the indicating LED on the controll panel will light on and the error information will be displayed on the error log which must be manually cleared for...

  • Page 31: Flow Chart Of Troubleshooting

    D Series Modular Air-cooled Scroll Chillers Service Manual 2 FLOW CHART OF TROUBLESHOOTING (1). High pressure protection ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 32 D Series Modular Air-cooled Scroll Chillers Service Manual (2). Low pressure protection ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 33 D Series Modular Air-cooled Scroll Chillers Service Manual (3). High discharge protection ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 34 D Series Modular Air-cooled Scroll Chillers Service Manual (4). Compressor over-load protection (5). Phase protection ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 35 D Series Modular Air-cooled Scroll Chillers Service Manual (6). (7). Temperature sensor error ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...

  • Page 36: Removals And Reinstallation

    D Series Modular Air-cooled Scroll Chillers Service Manual 3 REMOVALS AND REINSTALLATION 3.1 MAIN PARTS Appearance Name Function It drives the refrigerant cycle and turns the low- Compressor temperature, low pressure refrigerant vapor into high- temperature, high-pressure vapor. It is used to separate oil and refrigerant liquid from the Accumulator refrigerant vapor.
  • Page 37 D Series Modular Air-cooled Scroll Chillers Service Manual 3.2 Removal and Installation of Main Parts Compressor compressors in between and then follow the steps below. ) Note: Be sure there is no refrigerant in the pipeline system and the power supply is cut off.
  • Page 38 D Series Modular Air-cooled Scroll Chillers Service Manual 4. Loose Remove screws with an adjustable screws at the wrench or a socket wrench. base of the Collect screws in case of loss. compressor Remove four screws at the base Remove the compressor and do not damage the rubber pad.
  • Page 39 D Series Modular Air-cooled Scroll Chillers Service Manual 4-way Valve Steps Graphic Representation Instructions Remember the installation direction of the 1. Record the 4-way valve before removal. installation Remove the coil. direction of Wrap the 4-way valve prior to unbrazing...
  • Page 40 D Series Modular Air-cooled Scroll Chillers Service Manual Accumulator Note: Be sure to recover the refrigerant, prepare proper devices and tools and keep a good ventilation. Steps Graphic Representation Instructions 1. Remove the panel as Remove the panel as shown in the left...
  • Page 41 D Series Modular Air-cooled Scroll Chillers Service Manual 4. Remove the bolts at Remove bolts at the base with a wrench. the base Bolts 5. Remove Remove the accumulator accumulator. Connect the pipeline of the accumulator 6. Purge with the nitrogen tank and adhesive tape...
  • Page 42 D Series Modular Air-cooled Scroll Chillers Service Manual Tilt the accumulator and then drill a hole 7. Check if close to the bottom and then pour the oil needs to oil inside the accumulator to a prepared be added container.
  • Page 43 D Series Modular Air-cooled Scroll Chillers Service Manual the refrigerant. Steps Graphic Representation Instructions 1. Remove Remove four panels around the heat the panel as shown in the blind plug. 2. Loosen the pipeline Remove the pipeline connectors R e m o v e t h e m e t a l s h e e t s l o c a t e d and remove underside with a screwdriver.
  • Page 44 D Series Modular Air-cooled Scroll Chillers Service Manual 4. Loosen four screws Screws 5. Remove the shell-and- R e m o v e t h e s h e l l - a n d - t u b e h e a t tube heat 6.
  • Page 45 D Series Modular Air-cooled Scroll Chillers Service Manual Steps Graphic Representation nstructions 1. Remove the panel as Remove the panel as shown in the left shown in the 2. Remove the guard Remove the guard cover with a wrench. cover 3.
  • Page 46 D Series Modular Air-cooled Scroll Chillers Service Manual 4. Remove Remove the motor with a wrench. the motor 5. Remove Remove the frame. the frame Frame 6. Reinstall Reinstallation sequence: 1. frame; 2. the fan motor; 3. fan blades; 4. guard cover; 5.
  • Page 47 D Series Modular Air-cooled Scroll Chillers Service Manual Steps Graphic Representation Instructions Recover refrierant completly. Cut off the power supply. 1. Remove Remove the fan assembly and draw out the panel as the power cord of the fan motor and then...
  • Page 48 D Series Modular Air-cooled Scroll Chillers Service Manual 4. Place a new heat and vacuum Braze the pipeline. the system Vacuum the system until the pressure is as and then low as -1.0bar. charge The refrigerant charge and quality shall comply...
  • Page 49 D Series Modular Air-cooled Scroll Chillers Service Manual 3 Remove the connection Charge nitrogen during brazing. pipe of the Take care to prevent surrounding item from electronic being burnt down owing to high temperature during brazing. valve 4. Remove the electronic valve 5.

  • Page 50: Routine Maintenance

    D Series Modular Air-cooled Scroll Chillers Service Manual 6. Reinstall the electronic The coil shall be matched with the valve valve coil and The degree of vacuum shall be kept as low vacuum the as -1.0 bar. system and The refrigerant charge and quality shall comply...
  • Page 51 D Series Modular Air-cooled Scroll Chillers Service Manual Step 3: Open the valves at both the high-pressure and low-pressure sides and then start the vacuum pump until the gage reading is below -1bar. After that, let the vacuum pump lasts for another 0.5~1.0 hour.

  • Page 52: Exploded Views And Part List

    D Series Modular Air-cooled Scroll Chillers Service Manual 5 EXPLODED VIEWS AND PART LIST (1). Model: LSQWRF65M/NaD-M ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 53 D Series Modular Air-cooled Scroll Chillers Service Manual Parts List: LSQWRF65M/NaD-M for EL01500500 Name of part Part code 4304413214 Strainer 07210037 Magnet Coil 4300040064 Filter 07218603 Condenser Assy 0112110001001 Rear Panel 0154110000101P Sensor Sub-assy 39008000004G One Way Valve 0733420001 pipe connector...
  • Page 54 D Series Modular Air-cooled Scroll Chillers Service Manual (2). Model: LSQWRF80M/NaD-M ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 55 D Series Modular Air-cooled Scroll Chillers Service Manual Parts List: LSQWRF80M/NaD-M for EL01500520 Name of part Part code 4304413213 07331139 Magnet Coil 4300040064 4-way Valve 43000412 Filter 07414118 Pressure Protect Switch 4602001570 Pressure Protect Switch 4602001582 Pressure Protect Switch 4602001579...
  • Page 56 D Series Modular Air-cooled Scroll Chillers Service Manual (3). Model: LSQWRF130M/NaD-M ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 57 D Series Modular Air-cooled Scroll Chillers Service Manual Parts List: LSQWRF130M/NaD-M for EL01500510 Name of part Part code Rear Grill 01571100001 Condenser Assy 1 0112110001101 Lower panel 01541100005P 4-way Valve 43000339 4304413214 Filter 07218603 07331139 Condenser Assy 2 0112110001201 Lower panel...
  • Page 58 D Series Modular Air-cooled Scroll Chillers Service Manual (4). Model: LSQWRF160M/NaD-M ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
  • Page 59 D Series Modular Air-cooled Scroll Chillers Service Manual Parts List: LSQWRF130M/NaD-M for EL01500530 Name of part Part code Condenser assy 2 0112110002501 Rear Grill 01571100001 4304413213 Magnet Coil 4300040049 4-Way Valve 43000412 07331139 Filter 07414118 Pressure Protect Switch 4602001570 Condenser assy 1...
  • Page 60 JF00301781 ТОО "Everest climate" г. Алматы, Варламова 1а, тел. +7  727 230 00 10, e-mail:  info@aircon.kz, сайт: www.aircon.kz...
