Set description

Flashlight, 18650 Li-Ion 3200 mAh battery, magnetic USB charger,
headmount, clip, 2 spare O-rings, user manual.
The producer reserves the right to change the package at his own
discretion without modifying this manual. Specifications are sub-
ject to change without notice.

Initial Service

TO SET/REPLACE BATTERY
1. Unscrew the tailcap.
2. Place the battery with the positive contact (+) facing the head of
the flashlight.
3. Adjust the tailcap and tighten it as far as it can go.
The flashlight is ready for operation.
HOW TO CONNECT THE MAGNETIC CHARGER
Unscrew the tailcap to 1/4 of a circle and adjust the magnetic charger
to it.
CHARGER COLOR INDICATION
Charger not plugged in:
• Green — device is in waiting mode.
Charger plugged in:
• Green blinking — evaluation of battery voltage.
• Red blinking — unscrew the tailcap to 1/4 for charging.
REV_00-0000
• Orange blinking — USB power source voltage is too low for correct
continuation of charging or bad contact between charger and battery.
Clean the tailcap and the threads of the flashlight parts, use a differ-
ent power source.
• Red — charging with rated charging current is going on.
• Orange — USB power source voltage is too low, charging current is
reduced.
• Green — charging is finished.

Operation

Before use: Tighten the tailcap as far as it can go.
In OFF state
1 click: To turn on the last used mode.
Press and hold: To turn on Firefly mode of the last used light. Keeping
button pressed will start cycling through modes of the chosen light.
Release to select.
In ON state
1 click: To turn off the flashlight.
Press and hold: To start cycling through modes of the chosen light.
Release to select.
2 clicks: To switch between white and green light in any mode.
Add/Remove Strobe modes. Unscrew the tailcap to 1/4 while the
flashlight is off, press the button, tighten the tailcap while keeping the
button pressed and then unscrew it again.
Automemorizing. After switching off the last used mode is memorized
for quick access at next switching on.
Lock-out function. Unscrew the tailcap to 1/4 for protection from
accidental switching on.
Safe high brightness modes. Turbo modes give maximum brightness
until the temperature of the flashlight and discharge current of the
battery exceed critical values.
Safe Soft-Start System allows increasing runtimes, getting lon-
ger battery life and protecting the battery from overdischarge or
overheating.
Active real-time temperature control. When the temperature
becomes close to +58 °C, the brightness decreases, which allows
avoiding flashlight and battery overheating, as well as LED degrada-
tion. Under good cooling conditions, the flashlight delivers light without
stepping down.
