Set description

Flashlight, 18650 Li-Ion 3200 mAh battery, magnetic USB charger,
headmount, clip, 2 spare O-rings, user manual.
The producer reserves the right to change the package at his own
discretion without modifying this manual. Specifications are sub-
ject to change without notice.

Initial Service

TO SET/REPLACE BATTERY
1. Unscrew the tailcap.
2. Place the battery with the positive contact (+) facing the head of
the flashlight.
3. Adjust the tailcap and tighten it as far as it can go.
The flashlight is ready for operation.
HOW TO CONNECT THE MAGNETIC CHARGER
Unscrew the tailcap to 1/4 of a circle and adjust the magnetic charger
to it.
CHARGER COLOR INDICATION
Charger not plugged in:
• Green — device is in waiting mode.
Charger plugged in:
• Green blinking — evaluation of battery voltage.
• Red blinking — unscrew the tailcap to 1/4 for charging.
REV_00-0004
• Orange blinking — USB power source voltage is too low for correct
continuation of charging or bad contact between charger and battery.
Clean the tailcap and the threads of the flashlight parts, use a differ-
ent power source.
• Red — charging with rated charging current is going on.
• Orange — USB power source voltage is too low, charging current is
reduced.
• Green — charging is finished.

Operation

Before use: Tighten the tailcap as far as it can go.
In OFF state
1 click: To turn on the last used mode.
Press and hold: To start cycling through Firefly modes. Release to
select. Keeping button pressed will start cycling through Main modes.
In ON state
1 click: To turn off the flashlight.
Press and hold: To start cycling through Main modes from any mode. In
Firefly1 cycling through Main modes starts after cycling through Firefly
modes. Release to select.
2 clicks: To turn on Turbo mode from any mode. The second double click
brings back last used mode.
MOMENTARY ACCESS
Firefly. Press and hold the button in OFF state to start cycling through
Firefly modes. Release to select. Keeping button pressed will start
cycling through Main modes.
Main. Short click from OFF state activates Main mode if it was the last
used mode.
Turbo. Double click in any mode in ON state. The second double click
brings back last used mode.
Cycling through Main modes. In ON state press and hold the button
in any mode. Main modes will start switching cyclically. In Firefly1
cycling through Main modes starts after cycling through Firefly modes.
Release to select.
For activation of the timer, unscrew the tailcap to 1/4 while the
flashlight is off, press the button and tighten the tailcap while keeping
the button pressed.
Press and hold the button for 5 seconds. When the flashlight starts
flashing with the main LED, release the button. Press the button the
