required number of times to set the timer:
1 click – 2 min; 2 clicks – 5 min; 3 clicks and more – 10 min.
The main LED will flash from 1 to 3 times, confirming the action:
1 flash – 2 min; 2 flashes – 5 min; 3 flashes – 10 min.
After confirming the activation of the timer, the flashlight will work in
the previously selected mode for a specified period of time. The next
click turns the flashlight off and resets the timer.
To return to permanent on, unscrew the tailcap to 1/4 while the flash-
light is off, press the button, release it and tighten the tailcap.
Automemorizing. After switching off the last used mode is memorized
for quick access at next switching on.
Lock-out function. Unscrew the tailcap to 1/4 for protection from
accidental switching on.
Safe high brightness modes. Turbo modes give maximum brightness
until the temperature of the flashlight and discharge current of the
battery exceed critical values.
Safe Soft-Start System allows increasing runtimes, getting lon-
ger battery life and protecting the battery from overdischarge or
overheating.
Active real-time temperature control. When the temperature
becomes close to +58 °C, the brightness decreases, which allows
avoiding flashlight and battery overheating, as well as LED degrada-
tion. Under good cooling conditions, the flashlight delivers light without
stepping down.
Low battery level. When the battery voltage drops, the brightness
will begin to decrease in steps to ensure the safety of the battery
and the user. When the brightness of the mode (except Firefly modes
and Main1) drops below approximately 25% from the nominal value,
the main LED flashes 2 times. At critical level light output decreases
to Firefly1.
Warnings
For effective operation of the flashlight we recommend branded
18650 Li-Ion batteries without PCB (unprotected) no more than
70 mm long.
The flashlight can get hot in Turbo mode quickly and discharge the
battery with high current. Don't leave it without your attention as very
bright light might heat objects and cause fire.
For storage or transportation of the flashlight in a pocket or a bag
it is necessary to activate the lock-out function to ensure protec-
tion from accidental switching on.
It is forbidden to charge the battery inside the flashlight when the
ambient temperature is below 0 °C.
4 ENG USER MANUAL WIZARD C2
1. Always follow the instructions from this manual and recommenda-
tions on battery usage.
2. Apply only the recommended power sources.
3. Do not reverse battery polarity.
4. Do not modify or recast the flashlight and its components as it will
deprive you of the warranty.
5. Do not allow water or any other liquid to leak into the flashlight.
6. Do not aim a switched-on flashlight at people's or animals' eyes — it
can cause temporary blindness.
7. Do not allow children to use the flashlight without your assistance.
The producer will not be liable for any harm done to the user if it
was caused by improper use of the product.

Care and Storage

It is recommended to clean the threads and O-rings off dirt and old
grease once or twice per year. Remember that reliable protection from
water and dust cannot be provided by worn-out sealing. The fouling as
well as lack of grease cause fast wear-out of the threads and sealing
rings.
To clean the threads do the following:
1. Unscrew the tailcap and remove the sealing rings carefully with a
toothpick (do not use sharp metal objects as they can damage the
rings).
2. Wipe the sealing rings thoroughly with a soft cloth (or tissue). Do not
use solvents. If the sealing ring is worn out or damaged, replace it
with a new one.
3. Clean the metal threads with a brush using ethanol. Be careful not to
allow the applied liquid inside the flashlight, as it can cause malfunc-
tioning of the flashlight.
After cleaning, grease the threads and the sealing rings that have
been installed in place with polyalphaolefin-based silica grease, e.g.
Nyogel 760G. The application of other types of grease is unacceptable.
In case of active operation and exploitation in dusty environments, it is
recommended to clean and grease the parts as often as the necessity
arises.
WE DO NOT RECOMMEND leaving power supplies (especially
non-rechargeable) inside the flashlight for a long storage period, as
they can leak for various reasons and damage the inner parts of the
flashlight. If you want to keep your flashlight in a stand-by state with
REV_00-0004
