ENG USER MANUAL
Thank you for choosing the products of Armytek.
Please read this manual carefully before using the flashlight.

Specifications

1. Headlamp: simple one-hand operation, reliable headmount. Solid
body without long wires, weak rubber connectors and unnecessary
boxes. The flashlight is easily installed, removed and 180° rotatable in
the mount. Quick-release silicone ring provides additional fixation
2. Every Day Carry light: compact design, convenient side button,
special matt anti-abrasive finish without rough knurling. Robust
removable steel clip and strong built-in tail magnet
3. Sports flashlight: body made from durable and lightweight
aircraft-grade aluminium, improved shock resistance, constant light
without flickering. Multiple variants of installation, optional accessories
for mounting on sporting gear
• Possibility to set the timer for automatic switching-off
Model
Optics
Brightness stabilization type
Light output
Peak beam intensity
Hotspot : Spill
Beam distance
Modes, light output and runtimes (measured
with 18650 Li-Ion 3200 mAh battery until the
light output drops to 10% of the initial value)
Power source
Time of charging (18650 Li-Ion 3200 mAh battery)
Length/Body diameter/Head diameter
Weight without/with battery
Ingress protection, Submersion and Impact resistance
X All the above specifications are test results based on ANSI/PLATO FL 1-2019 Standard. The data may vary due to environment, heat dissipation and other factors.
2 ENG USER MANUAL WIZARD C2
Wizard C2 (white light)
TIR
DIGITAL (CPU brightness control)
1200 lm
2890 cd
70°:120°
108 m
Turbo
1200 lm/2 h 45 min (580 lm after 4 min)
Main3
390 lm/4 h 45 min
Main2
180 lm/11 h
Main1
40 lm/51 h
Firefly2 2 lm/26 d
Firefly1 0.11 lm/200 d
1x18650 Li-Ion
3 h 20 min
112 mm/20.4 mm/33 mm
64 g/114 g
IP68. Depth up to 10 m for 5 h. Height up to 10 m
• Convenient wide beam of fully upgraded optical system, steel bezel
and tempered glass with anti-reflective coating for protection of the
TIR-lens
• Innovative technology allows using any standard 18650 Li-Ion
battery. Full protection against short circuit even in case of contact
between magnetic connector and metal objects
• Active real-time temperature control to prevent overheating above
+58 °C and warning indication of low battery level
• Total protection from water, dirt and dust in accordance with IP68
standard — flashlight continues to work even after submersion at
10 meters depth. Withstands fallings from up to 10 meters
• Robust and water resistant magnetic connector
Wizard C2 (warm light)
1120 lm
2800 cd
106 m
1120 lm/2 h 45 min (540 lm after 4 min)
363 lm/4 h 45 min
167 lm/11 h
37 lm/51 h
1.9 lm/26 d
0.1 lm/200 d
REV_00-0004
