Specifications - Armytek VIKING PRO User Manual

ENG USER MANUAL
Thank you for choosing the products of Armytek.
Please read this manual carefully before using the flashlight.

Specifications

• Large central spot and wide side spill
• Pro Powerful electronics provides constant brightness even at a
temperature of -40 °C and not fully charged battery
• Special precisely calculated reflector for powerful wide LED and
tempered glass with anti-reflective coating create large central spot
and wide side spill at impressive brightness. Hotspot diameter is
20 meters at 100 meters distance
• Withstands any recoil due to improved springs and installation of the
driver inside a reinforced capsule filled with protective compound
• Standard 1 inch body is compatible with tactical accessories, including
original magnetic remote switch and magnetic mount for quick
one-motion attachment and removal
• Two-phase electronic button retained two levels of pressing similar to
mechanical switch, but became noiseless and 20 times more durable
• Non-flat button allows easy switching on of the flashlight with a palm
Model
Optics
Brightness stabilization type
Light output
Peak beam intensity
Hotspot : Spill
Beam distance
Modes, light output and runtimes (measured
with 18650 Li-Ion 3500 mAh battery until the
light output drops to 10% of the initial value)
Power source
Time of charging (18650 Li-Ion 3500 mAh battery)
Length/Body diameter/Head diameter
Weight without/with battery
Ingress protection, Submersion and Impact resistance
X All the above specifications are test results based on ANSI/PLATO FL 1-2019 Standard. The data may vary due to environment, heat dissipation and other factors.
2 ENG USER MANUAL VIKING PRO
Viking Pro (white light)
Textured reflector
FULL (constant light)
2200 lm
20800 cd
11°:40°
288 m
Turbo 2200 lm/1 h 33 min (940 lm after 3 min)
Main3 400 lm/5 h 13 min
Main2 150 lm/12 h 20 min
Main1 56 lm/32 h
Strobe2
2200 lm/15 Hz/3 h (940 lm after 3 min)
Strobe1 150 lm/15 Hz/23 h
1x18650 Li-Ion
3 h 40 min
160 mm/25.4 mm/41 mm
135 g/185 g
IP68. Depth up to 25 m for 5 h. Height up to 25 m
• Innovative technology allows using any standard 18650 Li-Ion
battery with 10A discharge current. Full protection against short
circuit even in case of contact between magnetic connector and metal
objects
• Solid body made from aircraft-grade aluminium, special matt anti-
abrasive finish without rough knurling
• Steel striking bezel with matt non-reflective black titanium coating,
which prevents location disclosure, is used for additional protection of
the optical system in the event of a fall and as a shock-crushing tool
• Active real-time temperature control to prevent overheating above
+58 °C and warning indication of low battery level
• Total protection from water, dirt and dust in accordance with IP68
standard — flashlight continues to work even after submersion at
25 meters depth. Withstands fallings from the 10th floor
• Size-adjustable wrist lanyard, injury-safe ergonomic silicone grip,
heavy-duty nylon holster and steel clip for even more convenient use
• Robust and water resistant magnetic connector
Viking Pro (warm light)
2050 lm
20180 cd
284 m
2050 lm/1 h 33 min (875 lm after 3 min)
370 lm/5 h 13 min
140 lm/12 h 20 min
52 lm/32 h
2050 lm/15 Hz/3 h (875 lm after 3 min)
140 lm/15 Hz/23 h
REV_00-0001
