ENG USER MANUAL
Thank you for choosing the products of Armytek.
Please read this manual carefully before using the flashlight.

Specifications

1. Headlamp: simple one-hand operation, reliable headmount. Solid
body without long wires, weak rubber connectors and unnecessary
boxes. The flashlight is easily installed, removed and 180° rotatable in
the mount. Quick-release silicone ring provides additional fixation
2. Every Day Carry light: compact design, convenient side button,
special matt anti-abrasive finish without rough knurling. Durable nylon
holster, robust removable steel clip and strong built-in tail magnet
3. Sports flashlight: body made from durable and lightweight
aircraft-grade aluminium, improved shock resistance. New springs for
better battery and driver protection, constant light without flickering.
Multiple variants of installation, optional accessories for mounting on
sporting gear
• Pro Max New generation electronics provides impressive light output
of 4150 lumens. Constant brightness even at low ambient temperatu-
res and not fully charged battery
Model
Optics
Brightness stabilization type
Light output
Peak beam intensity
Hotspot : Spill
Beam distance
Modes, light output and runtimes (measured
with 21700 Li-Ion 5000 mAh battery until the
light output drops to 10% of the initial value)
Power source
Time of charging (21700 Li-Ion 5000 mAh battery)
Length/Body diameter/Head diameter
Weight without/with battery
Ingress protection, Submersion and Impact resistance
X All the above specifications are test results based on ANSI/PLATO FL 1-2019 Standard. The data may vary due to environment, heat dissipation and other factors.
2 ENG USER MANUAL WIZARD C2 PRO MAX LR
Wizard C2 Pro Max LR (white light)
Smooth reflector
FULL (constant light)
4150 lm
8190 cd
35°:85°
181 m
Turbo2 4150 lm/3 h 15 min (900 lm after 50 sec)
Turbo1 1300 lm/3 h 20 min (900 lm after 12 min)
Main3
450 lm/7 h
Main2 150 lm/21 h
Main1 45 lm/64 h
Firefly2 7 lm/10 d
Firefly1
0.6 lm/62 d
Strobe3 4150 lm/10 Hz/6 h 50 min (900 lm after 2 min)
Strobe2 4150 lm/1 Hz/14 h (900 lm after 10 min)
Strobe1 150 lm/1 Hz/90 h
1x21700 Li-Ion, 1x18650 Li-Ion
5 h 20 min
121.5 mm/23.6 mm/34.4 mm
81 g/151 g
IP68. Depth up to 10 m for 5 h. Height up to 10 m
• Pro Multicolor temperature, battery level and state indication
• Special precisely calculated reflector for powerful wide LED and tem-
pered glass with anti-reflective coating create large central spot and
wide side spill at impressive brightness and throw distance
• Innovative technology allows using any standard 21700 Li-Ion or
18650 Li-Ion battery with 15A discharge current. Full protection
against short circuit even in case of contact between magnetic con-
nector and metal objects
• Active real-time temperature control to prevent overheating above
+58 °C
• Total protection from water, dirt and dust in accordance with IP68
standard — flashlight continues to work even after submersion at
10 meters depth. Withstands fallings from up to 10 meters
• Robust and water resistant magnetic connector
Wizard C2 Pro Max LR (warm light)
3870 lm
8100 cd
180 m
3870 lm/3 h 15 min (840 lm after 50 sec)
1210 lm/3 h 20 min (840 lm after 12 min)
420 lm/7 h
140 lm/21 h
42 lm/64 h
6.5 lm/10 d
0.5 lm/62 d
3870 lm/10 Hz/6 h 50 min (840 lm after 2 min)
3870 lm/1 Hz/14 h (840 lm after 10 min)
140 lm/1 Hz/90 h
