    ASSEMBLY INSTRUCTIONS CROXLEY 2 DRAWER RATTAN BEDSIDE IMPORTANT : READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR CROXLEY 2 DRAWER RATTAN BEDSIDE USE YOUR PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. Keep small children and pets away during assembly as there are small parts.
  • Page 3 Page 3 of 9...

  • Page 4: Parts List

    Hardware List Parts List Part Description Part Description Side Panel(Left) Cam Bolt Side Panel(Right) Cam Lock Top Panel Wooden Dowel Wooden Leg Threaded Blot Bottom Panel Metal Sheet Back Panel Domed head Screw Drawer Side(Left) Flathead Screw Drawer Side(Right) Handle+Screw Drawer Back Plastic Wedge+Screw Drawer Front...
  • Page 5 Attach drawer back panel(9) to drawer side panels(7) and (8) using threaded bolts D, Step 1: then slide the bottom panel (11) into the groove Step 2: Screw the cambolts (A) into the drawer front (10), then slide the drawer front (10) onto the drawer box Insert the cam locks (B) into the holes in the side panels (7) and (8) and rotate to lock onto the cambolts Cover the cams with the stickers (K) Attach the drawer handle (H) with the screw provided...
  • Page 6 Step 3: Attach the drawer runners DR and DL to the base of the drawer box using the flatheaded screws G DRx2 DLx2 (DR) (DL) Step 4: Attach the drawer runners (CL) and (CR) to the side panels (1) and (2) using the flatheaded screws (G) CRx4 CLx4 Gx12...
  • Page 7 Step 5: Screw the cambolts (A) and push the dowels (C) into the top panel (3) then slide the side panels (1) and (2) onto the top panel (3) Insert the cam locks (B) into the holes in panels (1) and (2) and rotate with a cross-headed screwdriver to secure Step 6: Slide the back panel (6) into the groove in the side and top panels Push dowels (C) into the bottom of the side panels (1) and (2);...
  • Page 8 Step 7: Attach the leg brackets (E) to the base panel (5) using screws (F) Fx20 Step 8: Screw the legs (4) into the leg brackets (E) then attach the pads (J) ； Insert the plastic wedges (I) into the back panel groove in the corners and secure with the supplied screws Page 8 of 9...

  • Page 9: Additional Information

    Ensure the head of any screw used has a diameter greater than the mounting hole and the fixing is safe and secure before use. Birlea Furniture advise you use the wall straps provided to further enhance the safety of this product.
