Assa Abloy RIXSON 998M Quick Installation Instructions

Rixson is a brand associated with Yale Security Inc., an ASSA ABLOY Group company. Copyright © 2016, Yale Security Inc.
All rights reserved. Reproduction in whole or in part without the express written permission of Yale Security Inc. is prohibited.
Magnet Mounting
Bracket Assembly
Magnet
* For Wiring
See Note 3
5/32" x 3/8" (4 x 9.5) Slot
for 2" x 4" (51 x 102)
Electric Box
(2 Places)
2" x 4" x 1-1/2"
10-32
(51 x 102 x 38)
Self-tapping Screw
Single Gang Electric Box
(2 Places)
(by others)
Notes:
1. Do not scale drawing.
2. Total projection 3-5/8" (92mm). (Includes electromagnet and armature assembly.)
3. Non-tri voltage magnets have two non-polarized wires to be connected. Tri voltage
magnets are connected using a terminal strip on back of magnet. One wire in
common and one wire in the appropriate voltage terminal (non-polarized). Ground
assembly to earth ground per state and local electrical regulations.
4. See step 1 of sheet 2 for Electric Box location. Anchor Electric Box to withstand a
Door
Cover
Armature
1"
(25.4)
10-32 x 1-1/2" Flat Head
Self-Tapping Screws
(2 Places)
998M Door Release
ASSA ABLOY, the global leader in door opening solutions
Backup Contact Plate Adjusting
Plate Screw Location
Door
Armature
Surface Applied
Concealed Mounting
Recommended for
Solid Wood Doors Only
CAUTION: Nicks and scratches on the magnet
surface will lessen or diminish the holding force of
the magnet. Do not remove protective cap, if
present, until last steps of installation.
1-13/16
(46)
minimum 50 lb. pull. Electric Box shown installed in a vertical position.
5. Door closing mechanism should have a 3 lb. closing force at the degree of door
opening where door armature and electromagnet engage.
6. Mounting of Electric Box should be reinforced to withstand shock of door opening.
Failure to do so will cause Box anchors to work loose.
7. All dimensions given in inches (mm).
8. See sheet 2 for more details.
Door
Plate
Core or Composite Type
2-3/4
(70)
2-5/8
Approx.
(67)
2-5/8
(67)
2-17/32
(64)
Lock Edge
of Door
Pull Side
of Door
SHEET
1 of 2
08/16
Thru Bolt Mounting
Recommended for
Hollow Metal, Hollow
Wood Doors
Backup Plate
#6-32 Set Screw
#12 x 1-1/2 FH
Phillips Wood Screw
(2 Places)
Door Plate
1/4-20 x 2-1/16" THMS
(2 Places)
®
RIXSON
ASSA ABLOY
www.rixson.com
TEMPLATE NUMBER
Rev
DR100275 1
