4. Technical specifications (II)
- 3 x M4 lateral female tripod thread
4.6. Easy mount
- 3 x M4 base female tripod thread
UNC 1/4" - 20
It can be mounted either on a plate (inferior screws) or on a tube (lateral screws).
4.7. Mounting accessories
A wide range of accessories can be used with the device. The ULP STD can be mounted on a flat service
and screwed on to different sizes of poles. It can also be used with an adaptor for poles of 39 mm.
* Please, visit our website and check all the accessories available and their possible combinations at
www.calypsoinstruments.com.
North Mark Position
Make sure the north mark
is perfectly aligned to the
north.
ULP STD User Manual
5
