- Page 1 WIDEBAND CX INSTALLATION GUIDE For Use With Euro 5 vehicles PARTS LIST WIDEBAND CX O2 SENSOR CABLE O2 SENSOR VELCRO PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION 200 ARDEN DR. BELGRADE, MT. 59714 800-992-4993 WWW.DYNOJET.COM IWB-PVEU-1...
- Page 2 INTRODUCTION Thank you for purchasing the Wideband CX (WBCX) from Dynojet Research. The WBCX module is the tuning tool for gathering Wideband Air Fuel Ratio data for monitoring engine performance. WBCX CAN PORT Use your Power Vision module to view and log WBCX CONNECT TO data;...
- Page 3 INSTALLING THE WBCX Secure the WBCX under the center dash console using the supplied Velcro. Be sure to clean the mounting surfaces thoroughly with the supplied alcohol swab. Attach the Power Vision reflash cable (included with your Power Vision) to the diagnostic port on the vehicle and to either CAN port on the WBCX.
- Page 4 TRUTH TRUTH IN IN PERFORMANCE PERFORMANCE 200 ARDEN DR. BELGRADE, MT. 59714 - 800-992-4993 - DYNOJET.COM © 2020-2022 DYNOJET RESEARCH ALL RIGHTS RESERVED...
