LED State
Red (flashing)
2. Audio input (block connector)
Block pin assignments:
◦ + : Audio +
◦ − : Audio −
◦ Ground symbol: Audio ground
3. Chassis ground screw
Provides an optional connection for microphone shield wire to chassis ground.
4. Audio output (block connector)
Balanced audio output connects to an analog device. Set the output level in Shure Designer software to match the input
sensitivity of the analog device.
Note: See front panel labels for block connector assignments.
5. USB port
Connects to a computer to send and receive any combination of input and output audio channels.
6. Power LED
On when device has PoE
7. Network LED
On when network connection is active
8. Network audio LED
Network Audio LED Behavior
LED State
Off
Green
Red
9. Encryption LED
Encryption LED Behavior
LED State
Off
Green
Red
Meaning
Problem detected with connected USB audio device
Meaning
No active signal.
Device is operating successfully.
Error has occurred. Refer to event log in web application
for details.
Meaning
Audio is not encrypted
Successful encrypted audio connection with another de­
vice
Encryption error. Possible causes:
Encryption is enabled on one device and not on another
Encryption passphrase mismatch
