Technical Data

Parameter
Front panel, W x H x D
Mounting depth
Front panel seal
Rear panel seal
Keyboard
material/Front
panel
Reverse side
material
Weight
Serial port
RS422/RS485
Serial port RS232C
Ethernet
USB
Memory slots
Real time clock
Power consumption
at rated voltage
Display
Active area of
display, W x H
Fuse
Power supply
Ambient
temperature
Storage temperature
Relative humidity
Approvals and
certifications
* See section Chemical Resistance
Beijer Electronics, MAEN041
EPC TA150 AM
398 x 304 x 6 mm
60 mm (160 mm including clearance)
IP 66
IP 20
Touch screen: Polyester on glass, 1 million finger touch
operations. Overlay: Autotex F157 or F207*.
Powder-coated aluminum
3.7 kg
25-pin D-sub contact, chassis-mounted female with
standard locking screws 4-40 UNC
9-pin D-sub contact, male with standard locking screws 4-40
UNC
2 x shielded RJ 45
Host type A (USB 2.0), max output current 500 mA
1 x SD card
±30 PPM + error because of ambient temperature. Total
maximum error: 77 seconds/month at 25 °C.
Temperature coefficient: -0.034±0.006 ppm/°C
Rechargeable battery.
Normal: 1.2 A
Maximum: 1.7 A
TFT-LCD.1024 x 768 pixels, 64K colors.
CCFL backlight lifetime at the ambient temperature of
+25 °C: >35,000 h.
304.1 x 228.1 mm
Internal DC fuse, 3.15 AT, 5 x 20 mm
+24 V DC (20 - 30 V DC). Power supply connector.
CE: The power supply must conform with the requirements
according to IEC 60950 and IEC 61558-2-4.
UL and cUL: The power supply must conform with the
requirements for class II power supplies.
Vertical installation: 0 ° to +50 °C
Horizontal installation: 0 ° to +40 °C
-20 ° to +70 °C
5 - 85 % non-condensed
Information is available on the web site
www.beijerelectronics.com
for more information.
