LEGRAND HPM EF100SQWE Quick Start Manual

EF100SQWE
EF150SQWE
Standardsquare100mm
Standard square
Wall fan
150mm wallfan
Please read carefully: Read through these instructions completely before commencing installation. Retain for future use.
This product should be installed by a licensed electrical contractor or similarly qualified person.
Product Specifications
1
Cat. No. EF100SQWE
Supply Voltage
Power Rating
Standby Power
Wall cut-out size
Class of Protection
IP44
IP Rating
Draft stopper
Size
Fascia
30 mm
Protrusion
-
Size
External
wall Grille
-
Protrusion
500 g
Weight (excl.packaging)
Sound Pressure Level
Contents
Cat. No. EF100SQWE
Exhaust Fan
Draft Stopper
Instruction Manual
Warranty Card
Wall Mount screws &Plugs
External wall Grille to suit
Ø100 mm duct
Airflow*(m2/hr)
Cat. No. EF100SQWE
with
Draft stopper
68
No duct
Wall kitR621/4D* (with
350mm ofduct also
33
included in
EF100SQSWEKIT)
33
1m of Duct*
EF100SQSWE/EF100SQSWEKIT,
EF150SQSWE
EFT100SQSWE (Timer Integrated)
Slimline square
Slimline square 100mm wall fan
150mm wallfan
EF100SQSWE
EFT100SQSWE EF100RDWE
EF100SQSWEKIT
230-240 V a.c 50 Hz
14 W
0.8W (EFT100SQSWE only)
Ø110mm
Class II
IP24
PET Sheet
158x158 mm Ø190 mm
17 mm
125x125 mm
17 mm
450 g
30 dBA at 3m
(Tested in accordance with AS1217.5)
EF100SQSWE
EFT100SQSWE EF100RDWE
EF100SQSWEKIT
1 pc 1 pc
1 pc 1 pc
1 pc 1 pc
1 pc 1 pc
1 set 1 set
EF100SQSWEKIT only
EF100SQSWE EFT100SQSWE
EF100RDWE EF100SQSWEKIT
without with without
94 81
68 48
60 46
EF100RDWE
EF150RDWE
Round 100mm wall fan
Round
150mm wallfan
For indoor use only.
*Measured with Ø100mm ducting.
Airflow will be reduced with bends in duct, squashing of duct, restrictions on
replacement air entering the room to be ventilated, or pressure-differentials
between the room and outside air.
The length of the duct will have an effect on the airflow. When fitted, the
wall kit (R621/4D) must be at the same height or lower than the exhaust fan.
EF100SQSWEKIT includes: 1) External grill with mesh
2
Mounting
-
-
These exhaust fans are designed for wall-mounting only.
They may be vented into acavity wall. Alternatively,the fanmay be ducted through an
outside wall (with the addition of ducting and an out side grille).Protrusios into wall
cavity are as per below figures.
1 pc
Fan only
1 pc
1 pc
1 pc
1 set
Fan with draft
stopper
CAUTION:
Regulations concerning the discharge of air must be fulfilled.
Local building codes may require venting to the outside. Locate in accordance with the
105 requirements of the Wiring Rules AS/NZS 3000 relating to damp situations.
Note: Steam will only be removed if there is sufficient flow of air through the room.
Ensure adequate inlet openings in the room are provided, for example through
75
windows, vents orunder the door. Air-flow paths from room inlets to fan should ideally
pass over surfaces where condensation may form.
66
Wall Exhaust Fan - 100mm
Cat. No. EF100SQWE,EF100SQSWE,
EF100RDWE,EFT100SQSWE,
EFS150SQWE
Standard 150mm
wall fan with auto
shutter
2) Ø100mm X 350mm duct
3) Cable ties
4) Duct tape
5) Mounting screws
Wall
Wall/Ceiling
Draft Stopper
Draft Stopper
Wall/Ceiling Wall
EF100SQSWEKIT
Instruction Manual
EFS150SQSWE,
EFT150SQSWE,
EFH150SQSWE
Slimline 150mmwall
Fan with auto shutter
