Step 1. Concrete Ceiling - Create WIND TUBE Assembly Manual

PA RT S A N D TO OLS
A
Disassemble the part D separating it into pieces.
1
Mark with a pencil 2 parallel holes using
the part A as a guide.
3
insert the pieces D1 in the ceiling holes.
8 E NGL I SH
STEP 1. C ONC RE T E C EI L I NG
D
(1) EXPANSION SCREWS
D
D1
A
D1
+
D2 D3 D4
2
With the help of a drill, make the two cor-
responding holes with a Ø8 mm bit.
4
A
place the piece A matching their holes
with the screws D. Make sure that the ca-
bles from the ceiling go through the center
hole of the piece A.
MATERIAL NOT INCLUDED
+
Ø8mm
