- Page 1 Mira Sport Single Outlet Shower Fittings For SPARES, ADVICE or REPAIRS please call us free on 0800 001 4040 (UK only) These instructions must be left with the user Installation and User Guide 1546402-W2-A...
-
Page 2: Recommended Usage
Introduction Thank you for choosing a Mira showers. To enjoy the full potential of your new shower fittings, please take time to read this guide thoroughly, and keep it handy for future reference. Guarantee Mira Showers guarantee this product against any defect in materials or workmanship for a period of one year for the shower fittings, and two years for the diverter. -
Page 3: Pack Contents
Pack Contents Non-Airboost Versions 2 x Cap 2 x Slide Bar Support 2 x Mounting Pack 1 x Slide Bar 1 x Showerhead Multimode 1 x Clamp Bracket 1 x Retaining Ring 1 x Shower Hose 2 x Hose Seal 1546402-W2-A... - Page 4 Pack Contents Airboost Versions 2 x Cap 2 x Slide Bar Support 2 x Mounting Pack 1 x Slide Bar 1 x Showerhead Multimode 1 x Clamp Bracket 1 x Retaining Ring 1 x Shower Hose 2 x Hose Seal 1 x Air Pipe with Connector and Diffuser 1546402-W2-A...
- Page 5 General Please read the important safety information and the operation section of this guide before using the shower fittings. Failure to follow the instructions provided with this shower fittings will invalidate the guarantee. 1. Installation of the shower fittings must be carried out in accordance with these instructions by qualified, competent personnel.
- Page 6 9. DO NOT install the shower or fittings where they may be exposed to freezing conditions. 10. The position of the shower fittings must provide a minimum air gap of 25 mm between the showerhead and the spill over level of any bath, shower tray or basin.
-
Page 7: Important Safety Information
Only Kohler Mira recommended accessories should be used. 10. When adjusting the handset mode, point the handset away from body and make sure that the water temperature has stabilised before continuing to shower. - Page 8 Install the Shower Fittings Mounting Bracket (x2) Locking Peg on top side Wall Plugs (x2) 8 mm Wall Screws (x2) Locking peg on underside Mark the wall fixing positions and drill two holes to suit the wall fixings. Caution! Do not drill into cables or pipes in the wall. Note: Installation fixing centres are 630 mm for the 660 mm slidebar.
- Page 9 Locking Peg on top side Hole Endcaps (x2) Slidebar Support (x2) Clamp Bracket Slidebar Retaining Ring Locking peg on underside Hole Install the clamp bracket, the hose retaining ring (smallest hole) and the slidebar supports to the slidebar. Note: Orientate the hole on the slidebar supports in line with the locking peg on mounting bracket.
- Page 10 Handset Shower Unit Green Conical Shower Hose Hose Retaining Washer Ring Red Conical Hose and Handshower Installation (Non-Airboost Version) Screw the red conical onto the outlet of the shower. Caution! DO NOT over tighten. Feed the hose through the hose retaining ring. Screw the green conical onto the handshower.
- Page 11 Push fit the air pipe connector into the outlet connector, then carefully tighten the shower hose onto the outlet connector. Note: Make sure air pipe connector is Note: Make sure the hose washer pushed fully home. is fitted and that the air pipe connector is pushed fully home into the outlet connector.
- Page 12 Cleaning Always read the IMPORTANT SAFETY INFORMATION for your shower. Many household and commercial cleaners, including hand and surface cleaning wipes contain abrasives and chemical substances that can damage plastics, plating and printing and should not be used. These finishes should be cleaned with a mild washing up detergent or soap solution, and then wiped dry using a soft cloth.
- Page 13 Airboost Version Unscrew the shower hose from the shower then pull the air pipe connector from the shower outlet. Connector Unscrew the shower hose from the showerhead, pull out the diffuser. Ensure the diffuser holes are free from scale, clean if necessary.
- Page 14 Spray Modes Mode 1 Mode 2 Mode 3 Mode 4 When adjusting the shower spray mode, DO NOT force the lever as product damage will occur. 1546402-W2-A...
- Page 15 Notes 1546402-W2-A...
-
Page 16: Customer Support
Kohler Mira Limited. Cromwell Road, Kohler France S.A.S. Cheltenham, 30 Boulevard de la Bastille, The company reserves the right Gloucestershire 75012 Paris, to alter product specifications GL52 5EP France without notice. 14648 1546402-W2-A © Kohler Mira Limited, July 2023...
