- Page 1 SPMAR20410T Spektrum AR20410T PowerSafe Telemetry 20 CH Receiver Spektrum AR20410T PowerSafe Telemetrieempfänger mit 20 Kanälen Récepteur de télémétrie PowerSafe 20 canaux Spektrum AR20410T Ricevitore Spektrum AR20410T PowerSafe Telemetry 20 CH Created 11/23 41201...
-
Page 2: Warranty Registration
WARNING AGAINST COUNTERFEIT PRODUCTS Always purchase from a Horizon Hobby, LLC authorized dealer to ensure authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with regards, but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM or Spektrum technology. -
Page 3: Specifications
AR20410T PowerSafe Telemetry Receiver The Spektrum™ AR20410T Receiver is full range with telemetry, and is compatible with all Spektrum™ DSM2 and DSMX technology transmitters. ® ® Perform the setup for the AR20410T receiver through a compatible Spektrum Transmitter with Forward Programming. The Spektrum PC Programmer can be used for firmware updates. -
Page 4: Receiver Diagram
Receiver Diagram Status Bind Batt 1 LED Batt 1 Power Switch Batt 2 LED Batt 2... - Page 5 Function 1 Voltage probe port 2 Temp sensor port 3 XBUS port 4 RPM sensor port 5 SD card slot 6 Synapse sensor port 7 USB-C programming port 8 Remote receiver port (R) 9 Remote receiver port (L) 10 Remote receiver port (B) 11 Primary remote receiver port (A) 12 RGB Status LED 13 Bind Button...
-
Page 6: Default Channel Assignments
Follow the channel assignments defined in your transmitter after going through configuration for your model. For electric models using a Spektrum Avian ESC, the throttle port should always be the #1 servo port, for Smart telemetry to function. Throttle will function in other channels, but there will not be telemetry. -
Page 7: Antenna Placement
A. ANTENNA PLACEMENT Spektrum Multilink technology gives you the protection of multiple remote receivers working together to deliver a robust control link, but your installation plays a critial role in the performance of the control link. - Page 8 PowerSafe system. POWERING ON THE AR20410T WITH POWERSAFE By default, the AR20410T may be powered on from the built-in button on the receiver case, or with an external power button connected to the switch port (Sw). Only use the included momentary button for remote switch functionality.
-
Page 9: Transmitter And Receiver Binding
See www.spektrumrc.com for more information about telemetry accesories. * A Y-harness may be used with a Spektrum Avian Smart ESC on the #1 servo port. Do not use a Y-harness for a conventional servo or ESC. -
Page 10: Initial Setup
IMPORTANT: Do not use open mixes for primary flight control setup on the AR20410T when using a Synapse for AS3X+ and SAFE. If necessary, refer to aux output setup online to add stabilization to secondary functions. -
Page 11: Range Testing
Range Testing Before each flying session, and especially with a new model, it’s important to perform a range check. All Spektrum aircraft transmitters incorporate a range testing system, which reduces the output power to allow a range check. With the model resting on the ground, stand approximately 100 feet (30 meters) away from the model. -
Page 12: Flight Log
If your system displays a hold, diagnose the cause and resolve the issue before flying again. IMPORTANT: It is normal to see a hold logged if you power OFF your transmitter and back ON. IMPORTANT: The Spektrum Flight Log (SPM9540) is not compatible with the AR20410T receiver. - Page 13 Basic AS3X+ Setup (Synapse Sensor Required) Make sure your airplane is set up for flying (reversing, travel, subtrims, etc). Run through the First Time setup in forward programming and assign a channel for adjusting the gain such as the rotary knob or slider. Before flying, gyro response direction can be verified using the Gyro Response Test menu (Gyro Settings >...
- Page 14 Gyro Response Direction Test (when using a Synapse) This test ensures that the AS3X+ control system has the directions and any auxillary control surface configurations set up properly. Assemble the aircraft, bind your transmitter to the receiver, and complete the AS3X+ First Time Setup in the Forward Programming menu before performing this test.
- Page 15 If the control surfaces do not respond as shown, review the receiver mounting orientation. 1. In your transmitter’s menu select Forward Programming -> Gyro Settings -> System Setup -> Orientation 2. Verify the Synapse sensor orientation matches the selected diagram. The image of the airplane is from the top.
-
Page 16: Optional Accessories
Optional Accessories Optional Accesories SPMA3065 USB Programming Cable SPM9747 SRXL2 DSMX Remote Receiver SPM4651T SRXL2 DSMX Remote Receiver Telemetry Sensors and Accesories SPMA9500 Sky Remote ID Module SPMA95871 Aircraft Telemetry GPS Sensor SPMA9551 12" Aircraft Telemetry Extension SPMA9552 24" Aircraft Telemetry Extension... - Page 17 Troubleshooting Guide AS3X+ (when using a Synapse) Problem Possible Cause Solution Damaged propeller or Replace propellereller or spinner spinner Imbalanced propel- Balance the propellereller lereller Replace parts or correctly align Motor vibration propellereller or other parts and tighten fasteners as needed Synapse sensor not Align and secure the sensor in mounted securely...
-
Page 18: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution Throttle not at idle Reset controls with throttle and/or throttle trim stick and throttle trim at lowest too high setting Throttle servo travel is Make sure throttle servo travel Aircraft will not lower than 100% is 100% or greater respond to throttle but responds to... - Page 19 Problem Possible Cause Solution Aircraft or transmitter is Move aircraft and transmitter too close to large metal to another location and attempt object, wireless source or connecting again another transmitter Rebind transmitter to the aircraft Bind plug left installed in and remove the bind plug bind port Aircraft will not...
-
Page 20: Year Limited Warranty
1-YEAR LIMITED WARRANTY What this Warranty Covers - Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship for a period of 1 year from the date of purchase. What is Not Covered - This warranty is not transferable and does not cover (i) cosmetic damage, (ii) damage due to acts of God, accident, misuse, abuse, negligence, commercial use, or due to improper use, installation, operation or... - Page 21 https://www.horizonhobby.com/content/service-center-render-service-center or call the toll free telephone number referenced in the Warranty and Service Contact Information section to speak with a Product Support representative. Inspection or Services - If this Product needs to be inspected or serviced and is compliant in the country you live and use the Product in, please use the Horizon Online Service Request submission process found on our website or call Horizon to obtain a Return Merchandise Authorization (RMA) number.
-
Page 22: Warranty And Service Contact Information
(excluding fingers, hands, wrists, ankles and feet). This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Supplier’s Declaration of Conformity SPMAR20410T AR20410T 20 CH Receiver SPM9747 DSMX SRXL2 Remote Receiver SPM4651T Serial Telemetry Receiver This device complies with part 15 of the FCC Rules. -
Page 23: Fcc Information
• Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Horizon Hobby, LLC 2904 Research Rd., Champaign, IL 61822... -
Page 24: Compliance Information For The European Union
Compliance Information for the European Union EU Compliance Statement: SPMAR20410T Spektrum AR20410T 20 CH Receiver, SPM9747 DSMX SRXL2 Remote Receiver, SPM4651T Serial Telemetry Receiver; Hereby, Horizon Hobby, LLC declares that the device is in compliance with the following: EU Radio Equipment Directive 2014/53/EU;... - Page 25 © 2023 Horizon Hobby, LLC. Synapse, Avian, DSM, DSM2, DSMX, SAFE, AS3X, Spektrum Airware, SRXL2, SmartSafe, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
