- Page 1 AR6210 User Guide AR6210 Bedienungsanleitung Guide de l’utilisateur - AR6210 AR6210 Guida dell’utente...
- Page 2 DSM2 or Spektrum. AR6210 User Guide The AR6210 full range 6-channel receiver features DSM technology and is compatible with all Spektrum™ and JR® aircraft radios that support DSM2 and DSMX technology including: JR12X, JR11X, JRX9503, JRX9303, Spektrum DX8, Spektrum DX7, Spektrum DX6i, Spektrum DX5e, Spektrum Module Systems.
-
Page 3: Specifications
• Telemetry compatible Receiver Installation The AR6210 incorporates dual receivers, offering the security of dual path RF redundancy. An internal receiver is located on the main PC board, while a second external receiver is attached to the main board with a 6-inch extension. By locating these receivers in slightly different locations in the aircraft, each receiver is exposed to its own RF environment, greatly improving path diversity (the ability for the receiver to see the signal in all conditions). - Page 4 1. To bind an AR6210 to a DSM2 or DSMX transmitter, insert the bind plug in the BIND/DATA port on the receiver.
- Page 5 Red LED Hold Indicator The AR6210 features a red LED that indicates the number of holds that have occurred since the receiver was last powered on. The LED will flash the number of holds then pause (e.g., flash, flash, flash, pause, flash, flash, flash, pause indicates three holds occurred since the receiver was last turned on).
- Page 6 • The ESC’ s capability to deliver current to the receiver in electric aircraft • The switch harness, battery leads, servo leads, regulators etc. The AR6210 has a minimum operational voltage of 3.5 volts; it is highly recommended the power system be tested per the guidelines below.
