- Page 1 AR6610T User Guide AR6610T Bedienungsanleitung Guide de L’utilisateur - AR6610T AR6610T Guidea Dell’utente...
-
Page 2: Meaning Of Special Language
WARNING AGAINST COUNTERFEIT PRODUCTS. Always purchase from a Horizon Hobby, LLC authorized dealer to ensure authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with regards, but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM or Spektrum technology. -
Page 3: Specifications
DSM2 ® and DSMX technology. Perform the failsafe setup for the AR6610T receiver through a compatible Spektrum Transmitter with Forward Programming. The Spektrum PC Programmer can be used for fi rmware updates. SPECIFICATIONS AR6610T Type DSM2/DSMX 6 CH Telemetry Receiver... -
Page 4: Smart Throttle
Spektrum Smart batteries. If a standard ESC or servo is plugged into the throttle port on the AR6610T receiver, the throttle port will operate normally (PWM signal) like any conventional RC system. The AR6610T receiver is compatible with the Spektrum Avian line of ESCs for Smart Throttle. - Page 5 Double-sided tape or foam can be used to secure the receiver in place. TIP: The hard case can be removed to help the AR6610T fi t into a slim, car- bon fuselage. It is recommended to cover the bare receiver in heat shrink.
-
Page 6: Transmitter And Receiver Binding
Binding is the process of teaching the receiver the specifi c code of the transmitter so it will only connect to that specifi c transmitter. When new out of the package, the AR6610T will automatically go into bind mode the fi rst time it is powered on. - Page 7 • All other channels have no output until the receiver has linked to the transmitter. Forward Programming Verify your transmitter is updated your transmitter to the latest Spektrum AirWare™ software to take advantage of Forward Programming. See your transmitter manual for updating instructions.
-
Page 8: Receiver Power System Requirements
• The ESC’s capability to deliver current to the receiver in electric aircraft • The switch harness, battery leads, servo leads, regulators etc. The AR6610T has a minimum operational voltage of 3.5 volts; it is highly recommended the power system be tested per the guidelines below. -
Page 9: Flight Log
fl ying again. It is normal to see a hold logged if you power OFF your transmitter and back ON. IMPORTANT: The Spektrum Flight Log (SPM9540) is not compatible with the AR6610T receiver. -
Page 10: Range Testing
Range Testing Before each fl ying session, and especially with a new model, it’s important to perform a range check. All Spektrum aircraft transmitters incorporate a range testing system, which reduces the output power to allow a range check. 1. With the model resting on the ground, stand approximately 100 feet (30 meters) away from the model. - Page 11 Telemetry The AR6610T features full range telemetry and will provide receiver battery voltage, fl ight log data, and vario and altitude data without any additional sensors. The altitude and vertical speed (variometer) sensor (SPMA9589) functions are already integrated in the SPMAR6610T. Additional telemetry devices such as voltage sensors can be connected to the volt port, and XBus telemetry sensors can be connected through the XBus connector.
-
Page 12: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution Reset controls with throttle Throttle not at idle and/or stick and throttle trim at low- throttle trim too high est setting Aircraft will not Throttle servo travel is lower Make sure throttle servo travel respond to than 100% is 100% or greater... - Page 13 Problem Possible Cause Solution Move powered transmitter a few Transmitter too near aircraft feet from aircraft, disconnect and during connecting process reconnect fl ight battery to aircraft Aircraft or transmitter is too Move aircraft and transmitter close to large metal object, to another location and wireless source or another attempt connecting again...
-
Page 14: Year Limited Warranty
1-Year Limited Warranty What this Warranty Covers—Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship for a period of 1 year from the date of purchase. What is Not Covered—This warranty is not transferable and does not cover (i) cosmetic damage, (ii) damage due to acts of God, accident, misuse, abuse, negligence, commercial use, or due to improper use, installation, operation or maintenance, (iii) - Page 15 visit our website at www.horizonhobby.com, submit a Product Support Inquiry, or call the toll free telephone number referenced in the Warranty and Service Contact Information section to speak with a Product Support representative. Inspection or Services—If this Product needs to be inspected or serviced and is compliant in the country you live and use the Product in, please use the Horizon Online Service Request submission process found on our website or call Horizon to obtain a Return Merchandise Authorization (RMA) number.
-
Page 16: Warranty And Service Contact Information
2.400GHz to 2.4835GHz frequency range. Supplier’s Declaration of Conformity Spektrum AR6610T Telemetry Receiver (SPMAR6610T) FCC ID: BRWTIARLGTNNG This device complies with part 15 of the FCC Rules. Operation is subject... -
Page 17: Compliance Information For The European Union
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •... - Page 18 DSM, DSM2, DSMX, QuickConnect, ModelMatch, SmartSafe, Hangar 9 and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. All other trademarks, service marks and logos are property of their respective owners.
