Summary of Contents for IFM Electronic efector500 PN70 Series

  • Page 1 Operating instructions Pressure sensor PN70xx...
  • Page 2: Table Of Contents

    Contents 1 Preliminary note ���������������������������������������������������������������������������������������������������3 1�1 Symbols used ������������������������������������������������������������������������������������������������3 2 Safety instructions �����������������������������������������������������������������������������������������������3 3 Functions and features ����������������������������������������������������������������������������������������4 4 Function ���������������������������������������������������������������������������������������������������������������5 4�1 Processing of the measured signals ��������������������������������������������������������������5 4�2 Switching function ������������������������������������������������������������������������������������������5 4�3 Diagnostic function ����������������������������������������������������������������������������������������6 5 Installation������������������������������������������������������������������������������������������������������������6 6 Electrical connection ��������������������������������������������������������������������������������������������7 7 Operating and display elements �������������������������������������������������������������������������8 8 Menu ��������������������������������������������������������������������������������������������������������������������9 8�1 Menu structure �����������������������������������������������������������������������������������������������9...
  • Page 3: Preliminary Note

    1 Preliminary note 1.1 Symbols used ► Instruction > Reaction, result […] Designation of pushbuttons, buttons or indications → Cross-reference Important note: Non-compliance can result in malfunctions or interference� 2 Safety instructions • Please read this document prior to set-up of the unit� Ensure that the product is suitable for your application without any restrictions�...
  • Page 4: Functions And Features

    • When the damping device is removed the damping device can become unus- able� • When the damping device is removed the unit can no longer be used under UL conditions� If you have any questions, please contact ifm electronic’s sales specialists�...
  • Page 5: Function

    4 Function 4.1 Processing of the measured signals • The unit displays the current system pressure� • It generates 2 output signals according to the parameter setting� OUT1 • Switching signal for system pressure limit value� 2 options OUT2 • Switching signal for system pressure limit value� • Diagnostic signal (output 2 is inactive in case of a fault)�...
  • Page 6: 4�3 Diagnostic Function

    4.3 Diagnostic function Output 2 is used as diagnostic output based on the DESINA specification if [OU2] = [dESI]� • If there is no fault, the output is switched and carries UB+ (if P-n = PnP) or UB- (if P-n = nPn)� • In case of malfunctions in the following areas, the output is inactive: - Measuring cell defect, - short circuit in output 1,...
  • Page 7: Electrical Connection

    6 Electrical connection The unit must be connected by a qualified electrician� The national and international regulations for the installation of electrical equipment must be adhered to� Voltage supply to EN50178, SELV, PELV� ► Disconnect power� ► Connect the unit as follows: 2 x p-switching 2 x n-switching 4: OUT1...
  • Page 8: Operating And Display Elements

    7 Operating and display elements 3 4 5 6 Mode/Enter 1 to 8: Indicator LEDs - LED 1 to LED 4 = system pressure in unit of measurement as indicated on the label� - LED 4 not used for units with 3 adjustable units of measurement� - LEDs 5 and 6 not used�...
  • Page 9: Menu

    8 Menu 8.1 Menu structure...
  • Page 10: 8�2 Explanation Of The Menu

    8.2 Explanation of the menu SP1/rP1 Upper / lower limit value for system pressure at which OUT1 switches� SP2/rP2 Upper / lower limit value for system pressure at which OUT2 switches� Output function for OUT1: • Switching signal for the pressure limit values: hysteresis function [H ��] or window function [F ��], either normally open [�...
  • Page 11: Parameter Setting

    9 Parameter setting During parameter setting the unit remains in the operating mode� It continues its monitoring function with the existing parameters until the parameter setting has been completed� 9.1 General parameter setting 3 steps must be taken for each parameter setting: Parameter selection ►...
  • Page 12 ► Press [Set] and keep it pressed until Mode/Enter Set the valid code no� is displayed� ► Press [Mode/Enter] briefly� On delivery by ifm electronic: no access restriction� ► Press [Set] briefly� > The first parameter of the sub-menu Mode/Enter Set is displayed (here: [Uni])�...
  • Page 13: 9�2 Configuring The Display (Optional)

    9.2 Configuring the display (optional) ► Select [Uni] and set the unit of of measurement: - [bar], [mbar], [MPa], [kPa], [PSI], for PN7007 and PN7009 in addition [inHg]� ► Select [diS] and set update rate and orientation of the display: - [d1]: Update of the measured value every 50 ms�...
  • Page 14: 9�4 User Settings (Optional)

    9.4 User settings (optional) 9.4.1 Setting of a time delay for the switching signals [dS1] / [dS2] = switch-on delay for OUT1 / OUT2� [dr1] / [dr2] = switch-off delay for OUT1 / OUT2� ► Select [dS1], [dS2], [dr1] or [dr2] and set a value between 0�1 and 50 s (at 0�0 the delay time is not active)�...
  • Page 15: Operation

    10 Operation After power on, the unit is in the Run mode (= normal operating mode)� It carries out its measurement and evaluation functions and provides output signals accord- ing to the set parameters� Operating indications → chapter 7 Operating and display elements. 10.1 Reading of the set parameters ►...
  • Page 16: Scale Drawing

    11 Scale drawing 21,5 Dimensions are in millimeters = dimensions for PN7000 and PN7060 1: display 2: LED’s 3: programming button 12 Technical data Operating voltage [V] ������������������������������������������������������������������������������������������18���36 DC Current consumption [mA] ��������������������������������������������������������������������������������������������� < 50 Current rating per switching output [mA] ������������������������������������������������������������������������ 250 Reverse polarity protection, overload protection �������������������������������������������������...
  • Page 17 Accuracy / deviations (in % of the span) - Set point accuracy �������������������������������������������������������������������������������������������������� < ± 0�5 - Deviation of the characteristics ������������������������������������������ < ± 0�25 (BFSL) / < ± 0�5 (LS) - Hysteresis ������������������������������������������������������������������������������������� < 0�25 (1�0 for PN7060) - Repeatability (in case of temperature fluctuations < 10 K) ���������������������������������������< ± 0�1 - Long-term stability (in % of the span per 6 months) ���������������������������������������������...
  • Page 18: 12�1 Setting Ranges

    12.1 Setting ranges SP1 / SP2 rP1 / rP2 ΔP 5790 5760 0�4 40�0 0�2 39�8 0�2 3620 3600 0�2 25�0 0�1 24�9 0�1 1�0 100�0 0�5 99�5 0�5 1450 1440 0�10 10�00 0�05 9�95 0�05 0�2 25�0 0�1 24�9 0�1 0�02 2�50...
  • Page 19: Factory Setting

    SP1 / SP2 rP1 / rP2 ΔP 8700 8650 0�6 60�0 0�3 59�7 0�3 ΔP = increments 13 Factory setting Factory setting User setting 25% VMR* 23% VMR* 75% VMR* 73% VMR* bAr / mbAr * = the indicated percentage of the final value of the measuring range (VMR) of the corresponding sensor in bar / mbar is set�...
