Application pages

Each application connected to the system is presented on panels. All application
pages are accessed from the Home page.
No. Item
1
Application panel
2
Instrument bar
3
System controls dialog
4
Status bar
5
Dialog
6
Alarm message
7
Menu
Adjust panel size
Change the panel size for an active split page:
1.
Activate the System Controls dialog
2.
Select the adjust splits option in the dialog
3.
Adjust the panel size by dragging the adjustment icon
4.
Confirm your changes by tapping one of the panels or selecting the save option
in the menu
