- Page 1 CARLO GAVAZZI A u t o m a t i o n C o m p o n e n t s VariFlex RVDF Series Quick Start Guide 110V Class 1ph 0.20~0.75kW 0.25~1.0HP 220V Class 1ph 0.20~2.2kW 0.25~3.0HP Class 3ph 1.50~2.2kW...
- Page 2 If not re-used, these containers can be recycled. Polythene, used on the protective film and bags from wrapping product, can be recycled in the same way. Carlo Gavazzi packaging strategy favours easily recyclable materials of low environmental impact, and regular reviews identify opportunities for improvement.
-
Page 3: Table Of Contents
RVDF Quick Start Guide CONTENTS Chapter 1: Introduction ........... . 4 1.1 Electrical safety –... - Page 4 Chapter 4: Troubleshooting ..........19 4.1 Manual Reset Inoperative Malfunctions .
-
Page 5: Chapter 1: Introduction
RVDF Quick Start Guide Chapter 1: Introduction 1.1 Electrical Safety - general warning The voltages used in the drive can cause severe electrical shock and/or burns, and could be lethal. Extreme care is necessary at all times when working with or adjacent to the drive. Specific warnings are given at the relevant places in this guide. -
Page 6: Motor
In this case, consult Carlo Gavazzi or their authorised distributor. Specifications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network. 110909... -
Page 7: Equipment Supplied By Plug And Socket
RVDF Quick Start Guide 1.8.5 Equipment supplied by plug and socket Special attention must be given if the drive is installed in equipment which is connected to the AC supply by a plug and socket. The AC supply terminals of the drive are connected to the internal capacitors through rectifier diodes which are not intended to give safety isolation. -
Page 8: Chapter 2: Hardware Instructions And Installation
RVDF Quick Start Guide Chapter 2: Hardware Instructions and Installation 2.1 Sample Model No. Identification Inverter model RVDFA120075F Output power 220V 0.75kW 1HP Ordering Key RVDF A 1 10 075 F VariFlex AC Drive Frame Size AC Supply Phase Drive Voltage Rating Drive kW Rating Options 2.2 Type Selection... -
Page 9: Wiring Specification And Suitable Optionals
RVDF Quick Start Guide 2.4 Wiring Specification and Suitable Optionals Molded-Case Circuit Breaker / Magnetic Contact RVDFA110020 RVDFA110075 RVDFB340075 RVDFA110040 Model Type RVDFB120075 RVDFB120220 RVDFB340150 RVDFA120020 RVDFB120150 RVDFB240220 RVDFA120040 Molded-case circuit breaker Wire dimension Wire dimension Wire dimension Wire dimension (#14AWG) 2.0mm (#14AWG) 2.0mm 3.5mm... - Page 10 RVDF Quick Start Guide Application and precautions of Peripherals From the Power Source: • Apply the power source at the correct rated voltage to prevent from damaging the inverter. • A Power Disconnect or Circuit breaker must be installed between the AC power supply and the inverter.
-
Page 11: Description Of Inverter Terminals
RVDF Quick Start Guide 2.5 Description of Inverter Terminals 2.5.1 Descriptions of Main Circuit Terminals Symbol Description L1 (R) Main power input Single-phase: L1/L2(0.2~0.75 kW) or L/N L2 (S) Three-phase: L1/L2/L3 L3 (T) Extermal braking resistor terminal (Only for RVDFBxxxxxx) T1 (U) T2 (V) Inverter output to Motor... -
Page 12: Outline Dimensions
RVDF Quick Start Guide Descriptions of SW function Type of external signal 0~20mA analog signal (When F_11 is set to 1) 4~20mA analog signal (When F_11 is set to 2) 0~10 VDC analog signal (When F_11 is set to 1) 2.6 Outline Dimensions Enclosed Metal Frame to screw all the inverter GND connection... -
Page 13: Din-Rail Mounting Diagram
RVDF Quick Start Guide 2.7 Din Rail Mounting Diagram STEP 1 STEP 1 Aim and insert the 4 small retention ribs of the screwdriver inserting DIN Rail at the 4 it into the middle rib holes in rear panel of of DIN Rail and press inverter the screwdriver in... -
Page 14: Outline Dimensions
RVDF Quick Start Guide Outline Dimensions DATA RESET S T O P 117.23 133.57 133.00 Specifications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network. 110909... -
Page 15: Rvdf Size 1 - Ip65 Type
RVDF Quick Start Guide 2.10 RVDF Size 1 - IP65 Type 2.10.1 Installation NOTE : 1. Power supply cable : #14 AGE (2.0m Potentiometer 2. Motor cable : #16 AGE (1.25m REV-0-FWD DATA RESET SWITCH 3. Torque value of Screw : STOP POWER (1). -
Page 16: Rvdf Size 2 - Ip65 Type
RVDF Quick Start Guide 2.11 RVDF Size 2 - IP65 2.11.1 Installation NOTE: 1. Power supply cable: 220V #12AWG (3.5mm²) DATA R E S E T R U N STOP 400V #16AWG (1.25mm²) POWER SWITCH 2. Motor cable: Potentiometer 220V #14AWG (2.0mm²) REV-0-FWD SWITCH 400V #16AWG (1.25mm²) -
Page 17: Connection
RVDF Quick Start Guide 2.11.3 Connection 2.11.4 EMC Mounting NOTE: For ALL FILTER MODELS, additional items will be find inside the box including : [1] pc of EMC conformed waterproof (IP65) ferrite core; [1] pc of metal fastener; [1] pc of MF Zin 5-C screw. “CAUTION: if application use require to meet EMC regulation, you MUST first constrain the motor cables, close the ferrite core onto the motor cable outside the plastic enclosure as stated in the above diagram. -
Page 18: Chapter 3 Software Index
RVDF Quick Start Guide Chapter 3: Software Index 3.1 Keypad Operating Instructions CAUTION Do not operate keypad by screwdriver or other sharp-ended tool to avoid damaging keypad. 3.2 Brief Keypad Operation Flowchart (FREQ) (1) (FREQ) (Read) After 0.5s (Write) Note (1) Displayed setting of frequency when stopped. Display output frequency when running. Note (2) The setting of the frequency can be modified either when stopped or when running. -
Page 19: Parameter List
RVDF Quick Start Guide 3.3 Parameter List Factory Function Function Description Unit Range Note setting Factory Adjustment Accel. Time Accel. time 0.1s 0.1~999s *1 *3 Decel. Time Decel. time 0.1s 0.1~999s *1 *3 0: Forward/Stop, Reverse/Stop Operation mode 1: Run/Stop, Forward / Reverse 0: Forward Motor rotation direction 1: Reverse... -
Page 20: Chapter 4: Troubleshooting
RVDF Quick Start Guide Chapter 4: Troubleshooting 4.1 Manual Reset Inoperative Malfunctions INDICATION CONTENT POSSIBLE CAUSE COUNTERMEASURE Place a RC surge absorber in parallel with the Program error Outside noise interference noise generating magnetic contact EEPROM error EEPROM defective Replace EEPROM Voltage too high 1. -
Page 21: Special Condition Description
RVDF Quick Start Guide 4.4 Special Condition Description INDICATION CONTENT POSSIBLE CAUSE Zero Speed When F_11 = 0, F_7= 0 and frequency setting < 1 Hz Stopping When F_11 = 1, F_7<(F_6/100), and frequency setting <(F_6/100) 1. If the inverter is set to external operation (F_10 = 1) and direct start is disabled (F_28 =1), the inverter cannot be started and will flash SP1 when operation Fail to start directly switch turned to ON after applying power (see descriptions of F_28). - Page 22 RVDF Quick Start Guide 4.6 General Malfunction Examination Method ABNORMALITY CHECK POINT COUNTERMEASURE Is the wiring for analog frequency input correct? • Examining the wiring and correct it. Motor operation Is the operation mode setting correct? • Examining the wiring and correct it. speed fixed Is the loading too heavy? •...
-
Page 23: Chapter 5: Peripherals
RVDF Quick Start Guide Chapter 5: Peripherals 5.1 EMI Filter Specification Model Dimension (mm) Current (A) Inverter model RVDFA110020 - RVDFA120020F CFFB42-A10-R 133 x 51 x 44 RVDFA110040 - RVDFA120040F RVDFA110075 - RVDFA120075F CFFB42-A20-R 99 x 84 x 68 RVDFB120150F - RVDFB120220F only for 1-phase configuration RVDFB340075F - RVDFB340150F CFFB43-A10-R106... -
Page 24: Chapter 6: Parameters Table
RVDF Quick Start Guide Chapter 6: Parameters Table Inverter Customer Model Contact Using Site Phone Address Parameter Setting Parameter Setting Parameter Setting Code Content Code Content Code Content F-00 F-11 F-22 F-01 F-12 F-23 F-02 F-13 F-24 F-03 F-14 F-25 F-04 F-15 F-26... - Page 25 Over Hadstenvej 38, DK-8370 Hadsten NORWAY - Carlo Gavazzi AS SWITZERLAND - Carlo Gavazzi AG Tel: +45 89 60 6100 GREAT BRITAIN - Carlo Gavazzi UK Ltd Melkeveien 13, N-3919 Porsgrunn Verkauf Schweiz/Vente Suisse Fax: +45 86 98 15 30...
