- Page 1 Washing Machine User’s Manual 8104 H...
- Page 2 Please read this manual first! Dear Customer, We hope that your product which has been manufactured in modern facilities and passed through a strict quality control procedure will give you the best results. Therefore, we advise you to read through this manual carefully before using your product and keep it for future reference.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Your Washing Machine Time display ....20 Starting the Program ... . .20 Overview . -
Page 4: Your Washing Machine
Overview 1 - Detergent Drawer 4 - Control Panel 2 - Door 5 - Filter Cap 3 - Top Lid 6 - Height-adjustable feet... -
Page 5: Specifications
Specifications Models 8104 H Maximum dry laundry capacity (kg) Height (cm) Width (cm) Depth (cm) Net Weight (kg) Electricity (V/Hz.) 220-240 V / 50Hz Total Current (A) Total Power (W) 2000-2350 Spinning cycle (rpm max.) 1000 Specifications of this appliance may change without notice to improve the quality of the product. Figures in this manual are schematic and may not match your product exactly. -
Page 6: Warnings
Warnings Please read the following information. for 3 seconds to cancel the program Otherwise, there may be the risk of set in your machine before calling personal injury or material damage. the authorized service. Moreover, any warranty and reliability First Use commitment will become void. • To prepare your machine for General Safety washing, carry out your first washing • Never place your machine on a process without loading your carpet covered floor. Otherwise,... -
Page 7: Safety Instructions
for your machine. Turn off the machine, unplug it, turn • This appliance is not intended for use off the water tap and contact an by persons (including children) with authorized service agent. reduced physical, sensory or mental If there are children in your capabilities, or lack of experience and knowledge, unless they have house... -
Page 8: Installation
Installation Removing packaging C Keep the transportation safety reinforcement bolts in a safe place to reuse when the washing machine Tilt the machine to remove the needs to be moved again in the packaging reinforcement. Remove the future. packaging reinforcement by pulling the C Never move the appliance ribbon. -
Page 9: Connecting To The Water Supply
Connecting to the water machine is not in use. supply. Important: • The water supply pressure required to run the machine must be 1-10 bar (0,1 – 1,0 MPa). Attach a pressure- reducing valve if the water pressure is higher. • Connect the special hoses supplied with the machine to the water intake • Models with a single water inlet valves on the machine. -
Page 10: Electrical Connection
• In case the hose is elevated B The appliance must not be operated after laying it on the floor level or unless it is repaired! There is the risk close to the ground (less than of electric shock! 40 cm above the ground), water discharge becomes more difficult Destroying the packaging and the laundry may come out wet. material Therefore, the heights described in Packaging material can be dangerous to... -
Page 11: Initial Preparations For Washing
Initial preparations for washing Sorting the laundry • Empty pockets and remove all foreign objects such as coins, pens • Sort the laundry according to type and paper clips. If possible, turn of fabric, color, and degree of soiling pockets out and brush. and permissible water temperature. • Place small items like infants’ socks Always follow the advice on the and nylon stockings, etc. -
Page 12: Loading Door
Following weights are given as Detergent, softener and other cleaning agents examples. Add detergent and softener before Laundry type Weight (gr.) starting the washing programme. Bathrobe 1200 Never open the detergent dispenser Napkin drawer while the washing programme is Duvet cover running! Bed Sheet When using a programme without... - Page 13 Detergent quantity for prewashing 1/2 measure for main washing 1 measure an additional 1/2 with hard water measure Softener Put the softener into the softener compartment of the detergent dispenser. • Use the proportions recommended on the packet. • Never exceed the (> max <) level marking; otherwise, the softener will be wasted without being used. • If the softener has lost its fluidity, dilute dense softener with water before placing it in the detergent...
-
Page 14: Selecting A Program And Operating Your Machine
Selecting a Program and Operating Your Machine Control panel Figure 2 Spin Speed Adjustment Button Display Temperature Adjustment Button 4 - Program Selection Knob 5 - On/Off Button 6 - Time Delaying Button (+/-) Auxiliary Function Buttons 8 - Start/Pause/Cancel Button... -
Page 15: Display Symbols
Display symbols Figure 3 Main programs Depending on the type of textile, the following main programs are available: Each of these main programs comprise of a complete washing process, including washing, rinsing and, if required, spin cycles. A When selecting the program you are 2.a - Spin Speed Indicator going to use, always consider type 2.b - Temperature Indicator... -
Page 16: Additional Programs
by selecting the proper temperature longer period at 40°C and gives the according to the labels of your clothes. same result as the “Cottons 60°C” It is recommended to use appropriate programme, thus it saves energy. It is detergents for woolens. suitable for clothes for which you cannot Additional programs use the “Cotton 60°C” programme. -
Page 17: Special Programs
permissible water temperature while Economy Symbol choosing a program. C Always select the lowest required Shows energy saving programs and temperature selections. temperature. Higher temperature As "Intensive" and "Hygiene" programs means higher power consumption. C For further program details, see are long programs with higher temperature selections to ensure “Program Selection Table”... -
Page 18: Program And Consumption Table
Program and consumption table Auxiliary functions Selectable Programme temperature range °C Pamuklu 2.50 max. • • • • • • 90-Cold Pamuklu 60** 1.53 max. • • • • • • 90-Cold Pamuklu 0.95 max. • • • • • • 90-Cold Yorgan 0.60... -
Page 19: Auxiliary Functions
Auxiliary functions shortened. "F2” symbol lights up on the display. Auxiliary Function Selection Buttons • Use this function for smaller amounts or slightly soiled laundries. • Rinse Plus When this function (2c) is selected, washing and rinsing is performed with plenty of water. "F3” symbol lights up on the display. • İlave Su (Plus water) When this function is selected, washing and rinsing is made with plenty of water in “Cottons”, “Synthetics”, “Delicates”... -
Page 20: Time Display
drains the water, spins the laundry and 1. Press “Start/Pause/Cancel” button program completes. (Figure 2-10). “ : “ in the middle of Time display the screen will stop flashing. The Standby symbol (Figure 3-2k) will The display shows the time remaining light up. The Time delaying symbol for the program to complete while a (Figure 3-2h) will flash. The Start program is running. -
Page 21: Progress Of Program
Progress of program button (Figure 2-10) momentarily. The Standby symbol (Figure 3-2k) which The progress of a running program is indicates the machine is in standby shown through a number of symbols on mode lights up and the start symbol the screen. (Figure 3-2j) that shows the program has • At the beginning of each program started and is still continuing fades out. -
Page 22: Ending The Program Through Canceling
by pressing the 2nd and 4th auxiliary The program continues, pumps out the functions for 3 sec. “C:on” (Child-proof water and spins. The Standby Symbol lock is activated) label appears on the (Figure 3-2k) fades out and Start Symbol display. (Figure 3-2j) lights up. If you want to discharge the water only without spinning: Press “Start/Pause/Cancel” button (Figure 2-10). The Standby symbol (Figure 3-2k) will fade. The Start symbol (Figure 3-2j) will light up. The program continues and only drains the water. The same symbol will also be displayed whenever any button is pressed while End of program... -
Page 23: Quick Instructions For Daily Use
Quick instructions for daily use Preparation adding more laundry during a future 1. Turn the tap on completely. Check step only if the water level is low that the hose is connected tightly. enough to open the loading door or 2. Place the laundry in the machine. - Page 24 After the programme is finished Programme indicator symbols on the screen will remain lit after the programme is finished. “End” will appear on the screen. 1. Open the loading door and take out the laundry when the door locked symbol on the display fades out. 2. Press the “On/Off” button. 3. Turn the water tap off. 4. Remove any folds in the rubber seal on the loading door and check for debris.
-
Page 25: Cleaning And Care
Cleaning and care Detergent drawer such cases: Clean the drum with a stainless steel Remove any powder residue buildup in cleaning agent. Never use steel wool the drawer. To do this; or wire wool. 1. Press the dotted point on the siphon in the softener compartment and pull Outer cabinet and control towards you until the compartment panel... -
Page 26: Draining Any Remaining Water And Cleaning The Pump Filter
• Take out the filters on the flat ends of the water intake hoses together with the gaskets and clean thoroughly under streaming water. • Replace the gaskets and filters carefully and tighten the hose nuts by hand. Draining any remaining water If it is composed of one piece, hold it and cleaning the pump filter from both sides and open it by pulling Filter system in your machine prevents out. - Page 27 the container by pulling out the plug into their positions and pushing the at the end of the hose. If the amount upper part of it. of water to be drained off is greater than the volume of the container, replace the plug, pour the water out, then resume the draining process.
- Page 28 Solution suggestions for problems Cause Explanation / Suggestion Programme cannot be started or selected. Machine may have switched to Bring your machine to factory settings by turning self protection mode due to an the programme selection knob. (see, Ending the infrastructure problem (such as line programme through Cancelling) voltage, water pressure, etc.). Water in the machine. There may be some water in your machine when you receive it. This is It is not harmful to your machine.
- Page 29 The door is jammed. - Water level might be above the lower level of the door. - Machine might be heating up the water or it may be at the spinning - Run either the “Pump” or “Spin” programme. cycle. - Wait until the process is over. - Due to an electrical mechanism, - Wait until the process is over.
- Page 30 It continuously washes. Remaining time does not count down. - The machine will wait until there is sufficient In the case of a paused countdown amount of water to avoid poor washing results due while taking in water: to lack of water. Then the timer will start to count - Timer will not countdown until the down.
- Page 31 - Washing performance is poor: Oily stains appear on laundry. - Washing performance is poor: Bad odour - Such odours and bacteria layers are formed on the drum as a result of continuous washing at lower temperatures and/or in short programmes. - Oily accumulations on the drum may - Leave the detergent dispenser drawer as well have stuck to the laundry. as the loading door of the machine ajar after each - Oily accumulations on the drum may washing.
- Page 32 Clothes do not smell like the softener. - If the water hardness is higher, using insufficient amount of detergent can cause the laundry to become stiff in time. Use appropriate amount of detergent according to the water hardness. - Insufficient amount of detergent used. - If detergent is put in the prewash compartment - The detergent was placed into the although prewash cycle is not selected, machine...
- Page 33 Machine does work. Nothing is displayed on the screen. The plug might not be plugged in the mains outlet. Check the plug. Fuse may have blown. Check the fuse. Electricity may be cut off. Check the supply power. The “On/Off” button might have not Press this button. been pressed. The machine did not start after the program was selected and the «Start/Pause/Cancel» button was pressed. The front door may be ajar. The Rinse Symbol amongst the Program Indicator Symbols is flashing. (Subject to the model of your machine, water cut-off symbol may light up too) You can restart your machine by pressing the...
