Summary of Contents for Chipsee PPC-CM4-170
- Page 1 Industrial PC PPC-CM4-170 PN: CS12102RA4170 Content can change at anytime, check our website for latest information of this product. www.chipsee.com...
-
Page 2: Table Of Contents
Contents PPC-CM4-170 1. Product Overview 2. Ordering Options ® 2.1. Pi CM4 Module 2.2. Operating System 2.3. Optional Features 3. Specifications 4. Power Input 5. Touch Screen 6. Connectivity 6.1. RS232/RS485/CAN 6.2. GPIO Port 6.3. USB Connectors 6.4. LAN 6.5. WiFi & BT Module 6.6. -
Page 3: Ppc-Cm4-170
PPC-CM4-170 PPC-CM4-170 Front View Chipsee Page 3 of 29... - Page 4 PPC-CM4-170 Rear View Chipsee Page 4 of 29...
- Page 5 PPC-CM4-170 Side View 1 Chipsee Page 5 of 29...
- Page 6 PPC-CM4-170 Side View 2 Chipsee Page 6 of 29...
-
Page 7: Product Overview
Installation on an industrial cabinet • Integration with the existing equipment ® The PPC-CM4-170 industrial Pi PC is based around the powerful Raspberry Pi Compute ® Module 4, powered by the Quad Cortex -A72 processor with a processor speed of 1.5GHz. Chipsee... -
Page 8: Ordering Options
® The PPC-CM4-170 industrial Pi PC does not include the CM4 Raspberry Pi module by default. If you would like to purchase it with a CM4, you can select it at the Chipsee store during the ordering process. Operating System This product comes with a pre-installed Raspberry Pi OS. -
Page 9: Optional Features
PPC-CM4-170 Optional Features Optional Features The PPC-CM4-170 industrial Pi PC does not include the 3G/4G/LTE modules by default. These modules are optional and can be selected at the Chipsee store during the ordering process. Warning Installation, repair, and maintenance tasks should be performed by trained personnel only. -
Page 10: Specifications
PPC-CM4-170 Specifications Specifications The PPC-CM4-170 industrial Pi PC offers a broad range of performance and connectivity options for scalable integration, providing expandability according to future needs. Some of the key features are listed in the table below. PPC-CM4-170 ® Raspberry Pi CM4; Quad Cortex-A72 at 1.5GHz... - Page 11 The default product without the CM4 does not include a Wi-Fi/BT module. You can include a CM4 that has the Wi-Fi/BT module at the Chipsee store during the ordering process. This TF card is designed for storage expansion, as the TF card uses the same pins with WiFi, it can’t be used...
-
Page 12: Power Input
PPC-CM4-170 Power Input Power Input The PPC-CM4-170 industrial Pi PC can be powered by a wide range of input voltages: From 12V to 36V DC. It is a 3 Pin, 3.81mm screw terminal connector. As shown in the figure below. -
Page 13: Touch Screen
Use a high-quality Power Adapter Unit (PSU) with low EMR. You can also provide power from a battery. Make sure that the PPC-CM4-170 Power Input connector (pin 3) is properly connected to the Power System Ground to provide sufficient EMI shielding and eliminate the problem entirely. -
Page 14: Connectivity
Connectivity Connectivity There are many connectivity options available on the PPC-CM4-170 industrial Pi PC. It has 2 x USB 3.0 Host, 1 x USB OTG, 1 x Giga LAN (RJ45) Ethernet connector supporting up to 1 Gbps, and 4 x UART and 1 x CAN terminals (RS232/RS485/CAN). - Page 15 PPC-CM4-170 RS232/RS485/CAN RS232 / RS485 / CAN Pin Definition: Pin 2 CAN_L CAN BUS “L” signal Pin 3 RS485_5- CPU UART5, RS485 –(B) signal Pin 4 RS485_5+ CPU UART5, RS485 +(A) signal Pin 5 RS485_3- CPU UART3, RS485 –(B) signal...
-
Page 16: Gpio Port
PPC-CM4-170 GPIO Port GPIO Port The PPC-CM4-170 industrial Pi PC has a phoenix connector, as shown in the figure below. The table below gives details about the definition of every Pin. Attention In order to use the Isolated Output, you need to add an external Isolated Power to the VDD_ISO and GND_ISO. - Page 17 PPC-CM4-170 GPIO Port GPIO Connector GPIO Connector Pin Definition: Pin Number Definition Description Pin 12 24V_ISO Isolated Power +24V Input Pin 11 GND_ISO Isolated Ground Pin 10 OUT1 Isolated Output 1 Pin 9 OUT2 Isolated Output 2 Pin 8 OUT3...
-
Page 18: Usb Connectors
PPC-CM4-170 USB Connectors USB Connectors There are 2 x USB 3.0 Host, 1 x USB OTG onboard, as shown in the figure below. USB HOST Connectors Attention 1. These two USB host connectors can drive 500mA for each channel at most. -
Page 19: Lan
PPC-CM4-170 The 1 x Giga LAN provides Ethernet connectivity over standardized Ethernet cables as shown in the figure below. The integrated Ethernet interface supports up to 1 Gbps data throughput. These Giga LAN signals come from the CM4 module directly. -
Page 20: Wifi & Bt Module
WiFi & BT Module WiFi & BT Module The default PPC-CM4-170 without the CM4 does not include a Wi-Fi/BT module. If you include a CM4 that has the Wi-Fi/BT module, the product will have Wi-Fi/BT feature. The enclosed (CS12102RA4170P) variant of the product also includes an SMA connector for an external WiFi/BT antenna, as illustrated in the figure below. -
Page 21: 3G/4G/Lte Module
3G/4G/LTE Module 3G/4G/LTE Module The PPC-CM4-170 industrial Pi PC is equipped with a mini-PCIe connector that can connect to a 3G/4G/LTE module. The customer will also need a SIM Card Holder and a 3G/4G/LTE antenna to ensure 3G/4G/LTE works on the PPC-CM4-170. SIM card does NOT support hot plug. -
Page 22: Zigbee Module
Zigbee Module Zigbee Module The PPC-CM4-170 industrial Pi PC supports an onboard Zigbee module. The Zigbee controller is TI CC2531, and the Raspberry Pi forum supports it. For CS12102RA4170P, there is a connector on the backside of the case that you can use to connect the external Zigbee antenna, as described in the figure below. - Page 23 PPC-CM4-170 Zigbee Module Zigbee Antenna Attention The product does not come with the Zigbee module by default. Chipsee Page 23 of 29...
-
Page 24: Tf Card Slot
PPC-CM4-170 TF Card Slot TF Card Slot The PPC-CM4-170 industrial Pi PC features 1 x TF Card (micro SD) slot. A slot can address up to 128GB of memory. TF (micro SD) Card Slot Attention The SD is used for memory extension. It can’t be used for system boot-up. -
Page 25: Audio Connectors
PPC-CM4-170 Audio Connectors Audio Connectors The PPC-CM4-170 industrial Pi PC features some audio peripherals. It has 1 x 3.5mm audio output jack. Also, the PPC-CM4-170 industrial Pi PC has a miniature 2W internal speaker for audio reproduction, as well as a small buzzer for alarm/notification sounds. -
Page 26: Prog Button
PPC-CM4-170 PROG Button PROG Button The PPC-CM4-170 industrial Pi PC has one button for entering usb download mode, as shown in the figure below. When booting with the button being pressed, the Raspberry Pi will boot from the USB connector. You can use this feature to download the OS software to the internal eMMC. -
Page 27: Mounting Procedure
PPC-CM4-170 Mounting Procedure Mounting Procedure The PPC-CM4-170 industrial Pi PC can be mounted with 4 x M4 (6mm) screws using the VESA (100x100mm or 75x75mm) mount. The PPC-CM4-170 industrial Pi PC can be mounted with panel mount method, enabling simplified installation onto any standard mounting fixture. -
Page 28: Mechanical Specifications
PPC-CM4-170 Mechanical Specifications Mechanical Specifications CS12102RA4170P For CS12102RA4170P, the outer mechanical dimensions are 398 x 337 x 53.5mm (W x L x H). Chipsee Page 28 of 29... -
Page 29: Disclaimer
If you cannot find the solution you’re looking for, feel free to contact us. Please email Chipsee Technical Support at support@chipsee.com, providing all relevant information. We value your queries and suggestions and are committed to providing you with the assistance you require.
