- Page 1 12-Sound Track High-Sound-Quality Audio Processing Amplifier For iPhone users, please search "Alpine Music" in APP Store to download and install it; for Android users, please scan the QR code on the right to download and install it directly. ...
-
Page 3: Table Of Contents
Table of Contents Operating Instructions Description of mobile APP - Homepage (full sound Type of precautions ..........1 field) ..............11 Description of mobile APP - Homepage (sound Copyright notice zone) ..............12 Copyright notice ............ 3 Description of mobile APP - EQ ......13 Description of mobile APP - Channel .... -
Page 4: Operating Instructions
Please contact the dealer System matching from whom you bought the product to install it for When PXE-X120-8 is used with active division mode safety. to assign signals for speakers, please ensure that the Please do not disassemble or refit. -
Page 5: Copyright Notice
Copyright notice The text mark and logo of Bluetooth® are the registered trademarks that Bluetooth SIG, Inc. Alpine Electronics has been authorized to use these text marks and logos. Other trademarks and names all belong to their holders. Products with a High-Resolution mark conform to the standards defined by the Acoustical Society of Japan. Alpine Electronics has been authorized by the Acoustical Society of Japan to use the High-Resolution mark. -
Page 6: Tools That May Be Required (Depending On The Vehicle)
Tools that may be required (depending on the vehicle) Panel removing tool Socket Electric drill Torx screwdriver Phillips screwdriver Sleeve wrench Wrench Wire cutter Wire crimper Wire stripper Spectrum analyzer Oscilloscope Accessory list 2×8P speaker line 2×12P Input line Power cord Mounting bracket Machine tooth screw ×... -
Page 7: Diagram Of Device Interfaces
Diagram of device interfaces Vehicle audio player (sold separately) External Bluetooth Wired controller or Alpine media wired controller (sold separately) Vehicle audio player (sold separately) Vehicle battery External power amplifier (sold separately) -
Page 8: Description Of Device Interfaces And Their Functions
Description of device interfaces and their functions A USB2.0 cable can be used to connect the computer and perform tone USB 2.0 interface tuning and setting in detail. Volume adjustment, audio source selection and data recall can be Wired controller interface performed by connecting the wired controller. -
Page 9: Device Indicator Description
Device indicator description When the amplifier output is turned off or the device is turned off, the indicator light is off; Amplifier switch indicator when the amplifier output is turned on, the indicator light is constant When the PC software or mobile tuning software is connected, the indicator light flashes;... -
Page 10: Wire Pin Arrangement
Wire pin arrangement White/Black 16AWG ..High-voltage-level output channel H8- White 16AWG ....High-voltage-level output channel H8+ White/Black 16AWG ..High-voltage-level output channel H7- White 16AWG ....High-voltage-level output channel H7+ White/Black 16AWG ..High-voltage-level output channel H6- White 16AWG ....High-voltage-level output channel H6+ White/Black 16AWG .. - Page 11 Wire pin arrangement White/Black 20AWG ....High-voltage-level output channel H12- White 20AWG ......High-voltage-level output channel H12+ White/Black 20AWG ....High-voltage-level output channel H11- White 20AWG ......High-voltage-level output channel H11+ White/Black 20AWG ....High-voltage-level output channel H10- White 20AWG ......High-voltage-level output channel H10+ White/Black 20AWG ....
-
Page 12: Description Of Mobile App - Start Page
Description of mobile APP - Start page Encryption DSP treble protection Master volume Built-in power amplifier Share sound effect Save sound effect Local sound effect Online sound effects Shutdown delay X-Over divider data Reset device parameters Not connected EQ gain step size Channel gain step size Homepage Device temperature... -
Page 13: Field)
Description of mobile APP - Homepage (full sound field) Homepage Sound zone switch Master audio source Optical Coaxial Blue High tooth voltage voltage level level Master audio source attenuation Auxiliary audio source Optical Coaxial Bluet High ooth voltage voltage level level Pre-set sound effects Pre-set... -
Page 14: Description Of Mobile App - Homepage (Sound Zone)
Description of mobile APP - Homepage (sound zone) Homepag Sound zone Volume switch Master Sound Zone I audio source Optical Coaxial Bluetooth High voltage voltage level level Master audio source attenuation Volume Auxiliary audio source Optical Coaxial Bluetooth High voltage Low voltage level level... -
Page 15: Description Of Mobile App - Eq
Description of mobile APP - EQ Graphic EQ Parametric EQ Band Gain Direct Frequency Q value Reset EQ Restore EQ Slide left and right to select the output channel for EQ adjustment. There are 12 1 Output channel channels to choose from. Parametric EQ, Switch between Parametric EQ mode and Graphic EQ mode. -
Page 16: Description Of Mobile App - Channel
Description of mobile APP - Channel Channel Mute control One-key mute Reset prompt After system reset, the output mode of the power Unmute amplifier will change. Please confirm that the channels Reset channel Mute control of the high pitch speakers after system reset are the same with those of the current system, then increase the type volume and listen, so as to prevent the speakers from... -
Page 17: Description Of Mobile App - Delay
Description of mobile APP - Delay Delay Delay setting (CH-5) Cancel Delay group Front left high Normal Reverse phase phase frequency Front right high Normal Reverse phase phase frequency Front left medium Normal Reverse phase phase frequency Front right medium Normal Reverse phase... -
Page 18: Description Of Mobile App - Frequency Combination
Description of mobile APP - Frequency combination Frequency combination Switch prompt If you switch mode, the set data will be Active Passive cleared. Are you sure to continue? input input Cancel High voltage level 1 High voltage level 2 High voltage level 3 High... -
Page 19: Description Of Pc Software
Description of PC software - Homepage (full sound field) Clipping distortion indicator File Options Encryption Temperature Master Device Homepage Delay Frequency combination volume voltage Master audio source selection Master audio source attenuation Optical Coaxial Bluetooth High voltage level voltage level Auxiliary audio source selection Coaxial Bluetooth... -
Page 20: Description Of Pc Software - Homepage (Sound Zone)
Description of PC software - Homepage (sound zone) File Options Encryption Clipping distortion indicator Master TREBLE PROTECTION Homepage Delay Frequency Temperature combination volume Firmware update Sound Zone I Sound Zone I volume Noise threshold Built-in power amplifier Master audio source selection Master audio source attenuation X-Over divider data Sound zone switch... -
Page 21: Description Of Pc Software - Eq
Description of PC software - EQ File Options Encryption Clipping distortion indicator Temperature Homepage Delay Frequency Device Master combination voltage volume EQ gain Curve Front left high step size switch frequency Front right high frequency Front left medium frequency Front right medium frequency Front left low frequency... - Page 22 Description of PC software - EQ Push the fader left and right to adjust the channel gain, that it, to adjust the volume of 10 Channel gain the output channel; the adjustable range is: -60dB ~ +6dB. 11 Reset channel type You can set the current channel type as Factory setting.
-
Page 23: Description Of Pc Software - Delay
Description of PC software - Delay File Options Encryption Clipping distortion indicator Temperature Device voltage Master volume Homepage Delay Frequency combination Front right high frequency Front left high frequency Delay Delay group group Normal phase Normal phase Front left medium frequency Front right medium frequency Delay Delay group... -
Page 24: Description Of Pc Software - Frequency Combination
Description of PC software - Frequency combination File Options Encryption Clipping distortion indicator Master volume Homepage Delay Frequency Temperature Device voltage combination Passive input Active input High voltage level 1 High voltage level 2 High voltage level 3 High voltage level 4 High voltage level 5 High voltage level 6 High voltage level 7... -
Page 25: Technical Parameters Specifications
Specification parameters Dynamic range ≥100dB SNR (RCA) ≥100dB High-voltage-level CH1 ~ CH4: 150uVrms; CH5 ~ CH8: 105.6uVrms; Background noise RCA: 15.5uVrms Channel resolution ≥80dB ≤0.05% Input voltage High-voltage-level: 30Vpp; RCA: 6.5Vpp Output voltage High-voltage-level CH1 ~ CH4: 40Vpp; CH5 ~ CH8: 28Vpp; RCA: 6.5Vpp Rated power CH1 ~ CH4: 50W;... -
Page 26: Functional Parameters
Functional parameters 12 channels of high voltage level, 2 channels of RCA audio, high resolution Input signals Bluetooth, optical/coaxial Output signals 8 channels of high voltage level, 12 channels of RCA audio Signal gain of output channel Range: mute, -60.0dB ~ +6.0dB Type: parametric EQ, graphic EQ Frequency: 20Hz ~ 40kHz;...
