- Page 1 BUILT-IN GAS COOKING HOBS INSTALLATION ADVICES - INSTRUCTIONS FOR THE USE • CHW938X ALG • CHW938X MAG • CHG953WLX LPG • CHG938WPLX LPG CANDY HOOVER GROUP S.R.L. • Via Comolli 16 • 20861 Brugherio (MB) Italy...
-
Page 2: Declaration Of Ce Conformity
Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. -
Page 3: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 4 • Do not attempt to modify the technical characteristics of the appliance as this may become dangerous to use. The manufacturer declines all responsibility for any inconvenience resulting from the inobservance of this condition. • CAUTION: this appIiance must only be installed in a permanently ventilated room in compliance with the applicable regulations.
- Page 5 • The manufacturer declines all liability for injury to persons or damage to property caused by incorrect or improper use of the appliance. • WARNING: During use the appliance and its accessible parts become hot; they remain hot for some time after use. Care should be taken to avoid touching heating elements on –...
- Page 6 overvoltage category III conditions, means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. • WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised.
- Page 7 ADVICE ADVICE for the for the INSTALLER INSTALLER...
- Page 8 IMPORTANT : • The appliance is designed and approved for domestic use only and should not be installed in a commercial, semi commercial or communal environment. Your product will not be guaranteed if installed in any of the above environments and could affect any third party or public liability insurances you may have.
-
Page 9: Installation
INSTALLATION TECHNICAL INFORMATION FOR THE INSTALLER In order to install the cooker top into the kitchen fixture, a hole with the dimensions shown in fig. 1.2 has to be made, bearing in mind the following: • within the unit, between the bottom of the cooktop and the upper surface of a shelf there must be a clearance of at least 30 mm. - Page 10 FASTENING THE INSTALLATION BRACKETS (fig. 1.4) • Each cooker top is provided with an installation kit including brackets and screws for fastening the top to fixture panels from 2 to 4 cm thick. • Turn the cooker top upside down and fasten the brackets “A” to the appropriate socket holes, without tightening the screws “B”...
-
Page 11: Ventilation Requirements
VENTILATION REQUIREMENTS The appliance must be installed in compliance with applicable local regulations concerning ventilation and the evacuation of exhaust gases. Intensive and prolonged use may require extra ventilation, e.g. opening a window, or more efficient ventilation increasing the mechanical suction power if this is fitted. CHOOSING SUITABLE SURROUNDINGS The room where the gas appliance is to be installed must have a natural flow of air so that the gas can burn (in compliance with applicable local regulations). -
Page 12: Gas Section
GAS SECTION GAS INSTALLATION REQUIREMENTS Important ! This appliance must be installed and serviced only by a suitably qualified, • registered installer. The installer shall refer to the local standards in force. • Failure to install the appliance correctly could invalidate any manufacturer’s warranty. -
Page 13: Connecting The Cooktop To The Gas Supply
CONNECTING THE COOKTOP TO THE GAS SUPPLY The gas connection fitting (fig. 2.1) is made up of: • the floating nut; • the elbow; • the gaskets; The gas connection must be carried out by an authorised person according to the relevant local standards. - Page 14 ADDITIONAL GAS CONNECTION REQUIREMENTS When connecting the cooktop to the gas supply with rigid pipes or a flexible hose, make sure that: • You use rigid pipes or a flexible hose compliant with applicable local regulations. The flexible hose shall be of the correct construction for the type of gas being used and of the correct size to maintain the heat output of the appliance.
-
Page 15: Lubrication Of The Gas Taps
GAS MAINTENANCE Some models - for the gas category check the data label attached on the appliance TABLE FOR THE CHOICE OF THE INJECTORS G30/G31 Cat: I 3+ 28-30/37 mbar Nominal Reduced Ø injector BURNERS Power [kW] Power [kW] [1/100 mm] Auxiliary (A) 1,00 0,40... - Page 16 Some models - for the gas category check the data label attached on the appliance TABLE FOR THE CHOICE OF THE INJECTORS Cat: II 2H 3+ G30/G31 (Countries IT-ES-PT-IE-GB-CH) 28-30/37 mbar 20 mbar Cat: II 2E+3+ G30/G31 G20/G25 (Countries FR-BE) 28-30/37 mbar 20/25 mbar Nominal...
- Page 17 REPLACEMENT OF THE INJECTORS Auxiliary, If the injectors are not supplied they can semi-rapid, Fish be obtained from the “Service Centre”. and rapid burner Select the injectors to be replaced according to the “TABLE FOR THE CHOICE OF THE INJECTORS”. nozzle diameters, expressed...
- Page 18 SETTING THE MINIMUM OF THE Models with safety cut-off valves COOKTOP BURNERS In the minimum position the flame must have a length of about 4 mm and must remain lit even with a quick turn from the maximum position to that of minimum. The flame adjustment is done in the following way: •...
-
Page 19: Electrical Section
ELECTRICAL SECTION IMPORTANT: The appliance must be installed by a qualified technician according with the current local regulations and in compliance with the manufacturer instructions. Incorrect installation might cause harm and damage to people, animals or objects, for which the manufacturer accepts no responsibility. Connection to a good earth wiring system is absolutely essential. -
Page 20: Replacing The Power Supply Cable
REPLACING THE POWER SUPPLY CABLE WARNING: If the power supply cable is damaged, it must be replaced only by an authorized service agent in order to avoid a hazard. Use the same type of power supply cable. This cable must be connected to the terminal block following the diagram in fig. 3.1. NOTE: The earth conductor must be left about 3 cm longer than the others. - Page 21 ADVICE ADVICE for the for the USERS USERS...
-
Page 22: Features And Technical Data
FEATURES AND TECHNICAL DATA Fig. 1.1 Fig. 1.2 Fig. 1.3 Fig. 1.4 Fig. 1.5 Fig. 1.7 Fig. 1.6 Caution! NOTE: Do not cover the hob with aluminium The knobs and symbols may vary. foils. - Page 23 Fig. 1.8 Fig. 1.9 Fig. 1.10 Fig. 1.11 Fig. 1.13 Fig. 1.12 Fig. 1.14 Fig. 1.15 Caution! NOTE: Do not cover the hob with aluminium The knobs and symbols may vary. foils.
- Page 24 Fig. 1.16 Fig. 1.17 Fig. 1.18 Fig. 1.19 Fig. 1.20 Fig. 1.21 Fig. 1.22 Fig. 1.23 Fig. 1.25 Fig. 1.24...
-
Page 25: Control Panel Description
COOKING POINTS Auxiliary burner (A) ..........1,00 kW Semirapid burner (SR) ...........1,75 kW Rapid burner (R) ............3,00 kW Fish burner (F) ............2,65 kW Triple ring burner (TR) ...........3,50 kW Electric plate Ø 145 mm Normal ....1000 W (at 230 V) Rapid (red dot) ..1500 W (at 230 V) Electric plate Ø... -
Page 26: How To Use The Cooktop
HOW TO USE THE COOKTOP GAS BURNERS LIGHTING GAS BURNERS FITTED WITH SAFETY VALVE DEVICE Gas flow to the burners is adjusted by turning the knobs (illustrated in fig. 2.1 - ignite burner, following 2.3) which control the valves. instructions are to be followed: Turning the knob so that the indicator Press in the corresponding knob and points to the symbols printed on the panel... - Page 27 LIGHTING BURNERS WITHOUT SAFETY VALVE DEVICE NOTE: The knob and symbols may vary. ignite burner, following instructions are to be followed: Press in the corresponding knob and turn counter-clockwise (fig. 2.2) to the full flame position marked by the “ ”...
- Page 28 DUAL BURNER - SOME MODELS ONLY ( fig 1.12, 1.13, 1.23) The Dual Burner is a very flexible burner which allows different regulations and optimal cooking. It is composed by one inner and one outer crown: the inner and outer crown can be used together or separately.
-
Page 29: Choice Of The Burner
CHOICE OF THE BURNER On the control panel, near every knob there is a diagram that indicates which burner is controlled by that knob. The suitable burner must be chosen according to the diameter and the capacity used. The burners and pans must be used in accordance with the following instructions: DIAMETERS OF PANS WHICH MAY BE USED ON THE BURNERS BURNERS MINIMUM... - Page 30 SPECIAL WOK GRILLE - SOME MODELS ONLY (OPTIONAL) (figs. 2.6a - 2.6b - 2.7a - 2.7b - 2.8a - 2.8b) This special grille for woks should be placed over the pan-rest for the triple ring burner or Dual burner. Warning: •...
- Page 31 CORRECT WRONG Fig. 2.8a Fig. 2.8b...
-
Page 32: Electric Hotplate/S
ELECTRIC HOTPLATE/S PROPER USE OF THE ELECTRIC NORMAL HOTPLATE HOTPLATE/S (fig. 2.10) To switch on the normal hotplate, turn the When the pan comes to the boil, turn the knob (fig. 2.9) onto the desired position; heat down to the level desired. the numbers 1 to 6 indicate the working Remember that the hotplate will continue positions with the increase of temperature... - Page 33 ELECTRIC HOTPLATE USAGE TABLE Position TYPE OF COOKING of switch Switched OFF For melting operations (butter, chocolate). To maintain food hot and to heat small quantities of liquid (sauces, eggs). To heat bigger quantities; to whip creams and sauces. (vegetables, fruits, soups). Slow boiling, i.e.: boiled meats, spaghetti, soups, continuations of steam,...
-
Page 34: Cleaning And Maintenance
CLEANING AND MAINTENANCE GENERAL ADVICE COOKING HOBS WITH • Before you begin cleaning you must GLASS LID (optional) ensure that the hob is switched off. • It is advisable to clean when the appliance is cold and especially when cleaning the enamelled parts. •... - Page 35 STAINLESS STEEL ELEMENTS • Stainless steel parts must be rinsed with water and dried with a soft and clean cloth. • For persistent dirt, use specific non-abrasive products available commercially or a little hot vinegar. • Note: regular use could cause discolouring around the burners, because of the high flame temperature.
- Page 36 Fig. 3.1 Fig. 3.2 (*) Some models only MODELS WITH TRIPLE-RING BURNER Fig. 3.3 (*) Some models only...
- Page 37 MODELS WITH DUAL BURNER (*) Some models only Fig. 3.4 Fig. 3.5 Fig. 3.6...
- Page 38 CORRECT REPLACEMENT OF THE FISH BURNER (some models only - see pages 22, 23, 24) The burner must be correctly positioned; failure to do so can cause serious problems. Fit the flame spreader to the housing as shown by the arrows (see figs. 3.8). The burner correctly positioned must not rotate (fig.
- Page 40 The manufacturer will not be responsible for any inaccuracy resulting from printing or transcript errors contained in this brochure. We reserve the right to carry out modifications to products as required, including the interests of consumption, without prejudice to the characteristics relating to safety or function.
