June, 2023
ANADC2 / LNTDC2
DINING CHAIR
Assembly Instructions - Important:
Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when
assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or
information on other products, please visit our website: www.officestar.net or call or write us.
Advertisement
Related Manuals for OSP Home Furnishings LNTDC2
Summary of Contents for OSP Home Furnishings LNTDC2
- Page 1 June, 2023 ANADC2 / LNTDC2 DINING CHAIR Assembly Instructions - Important: Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or...
-
Page 2: Limited Warranty
1-800-950-7262, Monday through Friday 8:00 a.m. - 3:30 p.m. Pacific Time. To make a warranty claim, contact Parts Department. Provide model number, proof of purchase, description of the problem and obtain return authorization. At its option OSP Home Furnishings will: ®... -
Page 3: Parts List
PARTS LIST (B) Seat (2 PCS) (A) Backrest (2 PCS) (C) Front Leg (4 PCS) HARDWARE LIST DRAWING DESCRIPTION SIZE QUANTITY Bolt 5/16” x 1-5/8” 2 PCS 5/16” x 2-3/8” Bolt 8 PCS Bolt 5/16” x 3” 8 PCS Lock Washer 5/16”... - Page 4 STEP 1 DO NOT FULLY TIGHTEN BOLTS STEP 2 DO NOT FULLY TIGHTEN BOLTS...
- Page 5 STEP 3 DO NOT FULLY TIGHTEN BOLTS STEP 4 CAREFULLY TURN TO THE UPRIGHT POSITION. APPLY FIRM PRESSURE TO ALIGN. FULLY TIGHTEN ALL BOLTS.
