3.2
Front Panel
The front panel is provided with LEDS, which inform about the status of several
router functions.
Leds
OFF
Status
Switched
Off
Uplink No
SHDSL
lines
configured
IP
Not used
WLAN
Not used
Aux
No auto
configurat
ion
10
Figure 1. Front Panel
Green
Red
Switched On
Switched On &
& Operational
Not operational
All SHDSL
All SHDSL lines
lines are
are not
synchronized
synchronized
(loss of signal)
All IP
All IP interfaces
interfaces are
are down
up
Interface up
Auto
configuration
successfully
completed
ONE180 – Installation Manual
Blinking Red
Orange
Minimum one
configured
SHDSL line is not
synchronized
(loss of signal)
At least one
IP Interface
is not up
(example:
PPPoA not
connected)
Blinking
Green
Reboot in
progress
Minimum
one SHDSL
line is in the
progress of
synchroniz
ation
Traffic in
progress
Auto
configuratio
n in
progress
