Meyer Lot Pro LP-7.5 Parts & Installation Instructions

EZ Mount Classic Model LP-7.5, LP-8, LP-8.5 & LP-9
Item LP - 7.5 LP - 8.0
1 09400
2 09796
3 08486 ---------
3 ---------
3 --------- ---------
4 09362
5 12394
6 12449
7 20363
8 22083
16549
9 12750
10 13520
11 07017
12 08852
08152
13 09124
14 22331
15 22375
16 20406
17 22398
18 22274
Meyer Products LLC reserves the right, under its continuing product improvement program, to change construction or design details,
specifications and prices without notice or without inncurring any obligation.
Parts & Installation Instructions
Lot Pro™ Moldboards
12
1
11
16
17
10
18
16
LP - 8.5 LP - 9.0
09401 09402 09403
09133 09134 07259
--------- ---------
08692 08692 ---------
--------- 08318
09362 09362 09362
12394 12394 12394
12449 12449 12449
20363 20363 20363
22083 22083 22083
16549 16549 16549
12750 12750 12750
13520 13520 13520
07017 07017 07017
08852 08852 08852
08152 08152 08152
09124 09124 09124
22331 22331 22331
22375 22375 22375
20406 20406 20406
22398 22398 22398
22274 22274 22274
Parts indented are included in the assembly under which they are indented.
13
14
9
16
15
7
4
6
5

Parts List

Qty Description
1 Moldboard Assembly
1 • Cutting Edge
1 • Bolt C 1/2-13 x 1-3/4 & Locknut (Kit of 9 each)
1 • Bolt C 1/2-13 x 2 & Locknut (Kit of 10 each)
1 • Bolt C 5/8-11 x 2-1/4 & Locknut (Kit of 12 each)
2 • Mushroom Shoe Casting Assy.
1 •• Runner Shoe Casting
1 •• Runner Spacer
11 •• Flatwasher 1-1/4
1 •• Linch Pin
1 Pivot Bar & A-Frame Carton
1 • Pivot Bar LP Series
1 • A-Frame (3-1/2" x 29" x 23-1/2")
4 • Trip Spring
1 • Plow Marker Kit
1 • Hardware Bag
4 •• Eye Bolt w/ Locknut & Cap
1 •• Hex Head Pin 1 x 3-5/16"
2 •• Pivot Pin 1 x 8-3/4" w/grease fitting
4 •• Cotter Pin 3/16 x 1-1/2"
1 •• King Pivot Bolt 1-8 x 5-1/2" w/grease fitting
1 •• Hex Nut Slotted 1-8
Form 1-937
3
2
3
8
May 2008
