• Equipped with IODD data install function. This enables setting values and process data of the IO-Link de-
vice to be displayed on the display of this product, or displayed and controlled remotely on a display con-
nected to a host PLC via CC-Link IE Field/TSN transient communication, by installing a converted IODD
•
• A time stamp can also be added to the process input data. As a result, CC-Link IE TSN makes it possible to
read the time when the process input data was taken from this machine, as synchronized with the network
Additionally, adding parity information calculated from process input data and time information, it is possible
to ensure the integrity of process input data and time (data integrity: DI).
It is also possible to store the read time of the setting value from the IO-Link device within this product and
later read it from the host PLC.
• A rotary encoder can be connected as an SIO device to this product, and the high-speed counter current
value on the process data side can be sent to the host network master.
• The organic display and operation buttons enable the following actions from the front.
• Master parameter setting
• I/O assignment status monitoring
• Connected IO-Link device setting changes
• Connected IO-Link device process data monitoring
•
German, French, Spanish, Portuguese, Italian)
• The type ID (vendor ID and device ID) of the IO-Link device can be saved in the unit, enabling the device
• The IO-Link device settings can also be saved within the unit, enabling device settings that are saved prior
to device replacement to be uploaded (restored) from the unit to the replaced IO-Link device (both auto-
matic and manual methods are available).
• The front buttons of this product can be remotely controlled from a touch panel display using acyclic com-
munication.
