Irenis BLANKOM HDM-94oo-C Manual

•
HDM-94oo C or T oo = 08, 16, 24 x HDMI with DVB-C or T output
(Consider for orders: T = DVB-T output, I=ISDB-Tb and A=ATSC optional upon request)
•
MPEG4 AVC/H.264 HD/SD encoding
•
8, 16 or24 HDMI inputs with AVC/H.264 Encoding
•
MPEG-1 Layer 2, LC-AAC, HE-AAC and AC3 Pass through
•
8(T) or 12(C) Channels /Bouquets multiplexing DVB-C or –T
modulating RF outputs – non adjacent = agile
•
-20dB Test-Output port
•
1 ASI IN and 128 SPTS Inputs to select and mux into the output
channels
•
Nx MPTS IP output over UDP, RTP/RTSP
•
PID remapping/ accurate PCR adjusting/PSI/SI editing and inserting
•
USB FAT32 – TS player to mux an INFO channel
•
DVB-C/DVB-T/ATSC-T/ISDB-T RF out selectable (from factory) -> So
always use proper character when ordering: C/T/I/A
•
Web based management, LOGO / Text insertion
info@blankom.de
ENCODER-MODULATOR
Pictures are preliminary and subject to change
HDM-94oo-C or T
www.blankom.de
6th Generation
BLANKOM® IPTV
Headend Technology
Broadcast grade, high
performance MPEG4 HD
Encoder Modulator (8...24
HDMI to RF output).
The HDM-94xy C/T series
products are BLANKOM's
new breakthrough all-in-
one device, which integrate
encoding (SD/HD MPEG-
4/AVC H.264) and
modulating to convert
HDMI signals into
DVB-C/DVB-T/ATSC-T/ISDB-
Tb RF output.
The HDM-94xyC/T HD
encoder modulator is a
professional high
integration device which
includes encoding,
multiplexing and
modulating.
It supports 8...24 HDMI
inputs, ASI and maximum
128 IP input through the
GBE port. It modulates
DVB-C RF out with 8 (T) or
12(C) non-adjacent
carriers.
The modulator type can be
chosen from factory by
ordering C or T version
(Or even A = ATSC or I =
ISDB-T)
