Technical­Specifications
Connections
Power
Power Consumption
Dimensions (LxWxH),
w/oAntennas
Weight
Supported Video
Formats
Audio Format
Displays
Transmitting Power
Receiver Sensitivity
Bandwidth
Operating Temperature
Certification
Transmitter
1x SDI Input (BNC female)
1x SDI Output (BNC female)
1x HDMI Input (Type A female)
2x Antenna (RP-SMA male)
1x DC Input (4-pin female)
7,2 – 18,0V DC
< 8 W
143.5 x 74.5 x 21.4mm
5.1" x 2.8" x 0.9"
380g / 10.2oz
1080p (60, 59.94, 50, 30, 29.97,
25, 24, 23.98)
1080i (60, 59.94, 50)
720p (60, 59.94, 50)
SDI Embedded 2 Channel
Audio 24bit/48kHz
0.91" OLED panel
Less than 20 dBm
-
40MHz
32 – 100°F (Operation)
0 – 140°F (Storage)
CE, RoHs, FCC
Receiver
2x SDI Output (BNC female)
1x HDMI Output (Type A female)
5x Antenna (RP-SMA male)
1x DC Input (4-pin female)
7,2 – 18,0V DC
< 8 W
147.8 x 100 x 20mm
5.5" x 3.9" x 0.9"
540g / 13.3oz
1080p (60, 59.94, 50, 30,
29.97, 25, 24, 23.98)
1080i (60, 59.94, 50)
720p (60, 59.94, 50)
SDI Embedded 2 Channel
Audio 24bit/48kHz
0.91" OLED panel
5 LEDs for RSSI indicator
-
- 75 dBm
40MHz
32 – 100°F (Operation)
0 – 140°F (Storage)
CE, RoHs, FCC
