Technical Specifications

Connections
Power
Power Consumption
Dimensions (LxBxH), w/o
Antennas
Weight
Supported Video Formats
Audio Format
Displays
Transmitting Power
Receiver Sensitivity
Bandwidth
Operating Temperature
Certification
!16
Transmitter
1x SDI Input (BNC female)
1x SDI Output (BNC female)
1x HDMI Input (Type A female)
2x Antenna (RP-SMA male)
1x DC Input (4-pin female)
9.0 – 18.0V DC
< 8 W
143.5 x 74.5 x 21.4mm
380g
1080p(60, 59.94, 50, 30,
29.97, 25, 24, 23.98)
1080i (60, 59.94, 50)
720p (60, 59.94, 50)
576i (50)
480i (59,94)
SDI Embedded 2 Channel
Audio 24bit/48kHz
0.91 inch OLED panel
Less than 20 dBm
-
40MHz
0 – 40°C (Operation)
-20 – 60°C (Storage)
CE
Receiver
2x SDI Output (BNC female)
1x HDMI Output (Type A
female)
5x Antenna (RP-SMA male)
1x DC Input (4-pin female)
9.0 – 18.0V DC
< 8 W
147.8 x 100 x 20mm
540g
1080p(60, 59.94, 50, 30,
29.97, 25, 24, 23.98)
1080i (60, 59.94, 50)
720p (60, 59.94, 50)
576i (50)
480i (59,94)
SDI Embedded 2 Channel
Audio 24bit/48kHz
0.91 inch OLED panel
5 LEDs for RSSI indicator
-
- 75 dBm
40MHz
0 – 40°C (Operation)
-20 – 60°C (Storage )
CE
!
