PROLONGED HEAT EXPOSURE
Your DC-LINK system generates heat during normal operation and complies
with applicable surface temperature standards and limits. Avoid prolonged,
direct or indirect skin contact when the devices are in use because exposing
skin to hot surfaces for a long period of time may cause discomfort or burns.
ENVIRONMENTAL RESTRICTIONS
To prevent damage to your DC-LINK system, do not use or store the devices or
accessories in dusty, smoky, damp, or dirty environments. Leaving the devices
in places in which the temperature may exceed 60°C / 140°F may cause da-
mage to the devices or pose a fire risk.
RADIO FREQUENCE INTERFERENCE
Observe rules that prohibit the use of wireless technology in certain environ-
ments. Your devices are designed to comply with regulations governing radio
frequency emissions but use of such systems can negatively affect other elect-
ronic equipment.
RECYCLING
Please recycle all packaging, devices and accessories in accordance with U.S.
regulations.

Overview

The DC-LINK-CLR2 is a high-performance WHDI video transmission system which
transmits uncompressed video and audio signals. Maximum transmission range
(line of sight) for the LR2 is 700m / 2,300ft, maximum transmission range for the
ULR1 is 1.200m / 4,000ft with no latency (< 0.001 s delay).
NOTE: The actual transmission ranges depend on setup, alignment and a
variety of environmental influences. Also, the transmission power of the trans-
mitter affects the range of the receiver. Therefore, the transmission range of the
X.LINK-S1 receiver can be significantly more with a ULR1 transmitter than with a
CLR2.
Due to the conscious decision not to implement DFS (Dynamic Frequency
Selection) the device has a longer range, greater stability and better usability
than comparable systems that DO use DFS.
The transmitter and receiver both have 3G-SDI and HDMI connectors (Plug &
Play). When a video source is attached, the transmitter automatically selects
the input (SDI is prioritized). The receiver's 3G-SDI and HDMI outputs can be
used simultaneously.
