RUGGEDCOM M969
Equipment Manual, 10/2023, C79000-G8976-1039-05
2 4
Copper Ethernet Ports
Port Status LED
POWER 1 LED
POWER 2 LED
ALARM LED
RS-232 Console Port
Failsafe Output Relay
M12 Power Supply Port
Fiber Optic Ethernet Ports
3
5
9
Introduction
1.2 Description
