INSTALLATION INSTRUCTIONS AND PARTS LIST
1. Read instructions completely and check to make sure that all required parts (listed on the service
parts list) are on hand before starting the installation.
2. Follow the instructions included with the specific bracket package that you are using to mount
the brackets to your vehicle.
3. The step is pre-assembled from the factory. The serial number label is located on the front inside
drivers side step assembly.
4. Attaching the step to the mounting bracket:
4.1 Set the step on the mounting brackets, and slide each support mounting plate (item #9) inside
the oval step and above each bracket.
4.2 Using the supplied 5/16-18 x 1" black stainless steel hex bolt, washer, and serrated flange nut
(items # 10,11&12) attach the step assembly, support mounting plate and mounting bracket.
4.3 Set the step plate in the correct position and tighten all fasteners.
Torque all 5/16" fasteners to 19 LB FT.
MODELS:
477097, 477101, 477113 (EXTENDED CABS)
477102, 477108, 477114, 477125 (CREW CABS)
REGAL 7 OVAL STEPS (BOARDS ONLY)
UNIVERSAL APPLICATIONS
REV A 31JUL12
552088 SHEET 1 OF 3 07MAY12
Advertisement
Table of Contents
Related Manuals for Luverne 77097
Summary of Contents for Luverne 77097
- Page 1 INSTALLATION INSTRUCTIONS AND PARTS LIST MODELS: 477097, 477101, 477113 (EXTENDED CABS) 477102, 477108, 477114, 477125 (CREW CABS) REGAL 7 OVAL STEPS (BOARDS ONLY) UNIVERSAL APPLICATIONS 1. Read instructions completely and check to make sure that all required parts (listed on the service parts list) are on hand before starting the installation.
- Page 2 SERVICE PARTS LIST ITEM PART NO. DESCRIPTION 552074 REGAL 7 OVAL STEP, LH,96”,477097, EXT CAB 552075 REGAL 7 OVAL STEP, RH,96”,477097, EXT CAB 552076 REGAL 7 OVAL STEP, LH,100”,477101, EXT CAB 552077 REGAL 7 OVAL STEP, RH,100”,477101, EXT CAB 552078 REGAL 7 OVAL STEP, LH,112”,477113, EXT CAB 552079 REGAL 7 OVAL STEP, RH,112”,477113, EXT CAB...
- Page 4 INSTALLATION INSTRUCTIONS AND PARTS LIST APPLICATION: MODEL 400717 WHEEL TO WHEEL STEP BRACKETS: 2007 GM SILVERADO & SIERRA REGULAR/EXTENDED/CREW CAB PICKUPS READ INSTRUCTIONS COMPLETELY AND CHECK TO MAKE SURE THAT ALL REQUIRED PARTS (LISTED ON THE SERVICE PARTS LIST) ARE ON HAND BEFORE STARTING THE INSTALLATION. ATTACH THE MOUNTING BRACKETS TO THE VEHICLE AS FOLLOWS: [SEE FIG.
- Page 5 INSTALLATION INSTRUCTIONS AND PARTS LIST APPLICATION: MODEL 400717 WHEEL TO WHEEL STEP BRACKETS: 2007 GM SILVERADO & SIERRA REGULAR/EXTENDED/CREW CAB PICKUPS SERVICE PARTS LIST ITEM PART NO. DESCRIPTION PARTS INCLUDED IN THE BRACKET PACKAGE 551861 MOUNTING BRACKET,GRIP STEP 107182 WASHER- SPCR, NYLON, BLK, .312 ID X 1.24 OD X .25 THK 100180 M8 X 30 X1.25 SCR,SST,BZP 106998...
