Homecoming Storage Bed
D E S I G N E D I N 2 0 2 1
A S S E M B LY N O T E S | R E V 0 0
N E E D A H A N D ?
Contact us at service@bludot.com or
844.425.8368 for assistance.
@ B L U D O T
We design all our pieces in our Minneapolis studio. Follow
along on Instagram for some sneak peeks into the process.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BluDot Homecoming
Summary of Contents for BluDot Homecoming
- Page 1 A S S E M B LY N O T E S | R E V 0 0 N E E D A H A N D ? @ B L U D O T Contact us at service@bludot.com or We design all our pieces in our Minneapolis studio. Follow 844.425.8368 for assistance.
- Page 2 Box 1 Hardware Pack 8050 Threaded Rod M8 x 65mm Pt. 1606 Pt. 8056 Pt. 2001 8057 Half Moon Connec- Pt. 8057 Pt. 5013 Pt. 5000 Pt. 4999 Pt. 9034 Pt. 9016 2 | 8 4 4 . 4 2 5 . 8 3 6 8 H O M E C O M I N G S T O R A G E B E D...
- Page 3 Box 1 Parts Rear Brace Front Brace Center Support Center Leg Center Brace Front Leg Brace Box 2 Parts Headboard A S S E M B LY N O T E S S E R V I C E @ B L U D O T. C O M | 3...
- Page 4 Box 3 Parts Footboard Side Panel Side Rail Drawer Front Box 4 Parts Box 5 Parts Mattress Support Drawer Body 4 | 8 4 4 . 4 2 5 . 8 3 6 8 H O M E C O M I N G S T O R A G E B E D...
- Page 5 How to use the cam lock system Note direction of cam. Turn cam clockwise 1/2 turn or until tight. Note direction of cam. A S S E M B LY N O T E S S E R V I C E @ B L U D O T. C O M | 5...
- Page 6 Step 01 AT TA C H B R A C E S T O C E N T E R L E G . Using the provided hardware, attach the front brace and the rear brace to the center PT. 5 01 3 x 2 PT.
- Page 7 Step 02 AT TA C H T H E S I D E R A I L S A N D S T R E T H C E R S . Screw the legs to the stretchers. Then, attach the stretchers and side rails to the base using the provided wood dowels.
- Page 8 Step 03 AT TA C H T H E F O O T B O A R D. Attach the footboard to the stretchers and sid rails using the provided hardware. 8050 Threaded Rod M8 x 65mm 8057 Half Moon Connec- PT.
- Page 9 Step 04 I N S TA L L T H E S I D E PA N E L S . Attach the side panels using the provided hardware. Do not completely tighten the bolts. P T. 50 1 3 X 4 P T.
- Page 10 Step 05 AT TA C H T H E H E A D B O A R D. A: Screw the legs into the bottom of the footboard. B: Attach the footboard using the provided hardware. Tighten all of the hardware from step 4.
- Page 11 Step 06 AT TA C H C E N T E R S U P P O R T A N D D R A W E R S . Slide the center support into place as shown. Attach the drawers by setting the drawer slide on the drawer into the slides attached to the Note: There is an extra hole on the center support that is not used in assembly.
- Page 12 Step 07 I N S TA L L D R A W E R F R O N T S . Loosely install the drawer fronts using the provided hardware. PT. 1 60 6 x 8 P T. 9 0 1 6 x 1 After all bolts are installed, tighten the bolts.
- Page 13 Step 08 AT TA C H T H E P L AT F O R M . Place the platform panels on top of the side rails. Hook and loop fasteners will keep panels in place. A S S E M B LY N O T E S S E R V I C E @ B L U D O T.
- Page 14 Step 09 L E V E L T H E B E D. If necessary, level the bed by twisting the adjustable glides. If the side panels and drawer fronts are not aligned, remove the platform panels and loosen the bolts. Hold the side panels in the appropriate position and re-tighten the bolts.
- Page 15 A S S E M B LY N O T E S S E R V I C E @ B L U D O T. C O M | 1 5...
-
Page 16: Additional Information
Additional Information C LEAN Clean with a slightly damp, soft cloth. To remove dirt and fingerprints, use a quality cleaner formulated for wood furniture. Wipe completely dry with a soft cloth in the direction of the wood grain. B L U D O T D E S I G N & M A N U F A C T U R I N G , I N C . D E S I G N E D I N M I N N E A P O L I S , M N...
