6. Operation

6.1 Main switch
The robot lawn mower is equipped with a main
switch (7). Use the main switch (7) to switch the
robot lawn mower on (ON) and off (OFF) (Fig. 8).
Once the robot lawn mower has been switched
on, it is locked by a PIN.
6.2 Control panel
The robot lawn mower has already been pro-
grammed at the factory and default settings have
been made for it. However, these can be changed
if required. Even though the factory settings will
be suitable for most gardens, you should still
familiarize yourself with the available options ne-
vertheless.
Explanation of the LEDs on the control panel
(Fig. 9a)
50. Time LEDs: Display of the daily mowing time
51. Lock LED: Display of the button lock
52. Status LED: Status display of the robot lawn
mower and the area to be mown
53. Perimeter wire LED: Indication of whether
there is a perimeter wire error
54. Battery LED: Display of the battery charge
level
55. Alarm LED: Indication of errors or a triggered
rain sensor
Explanation of the button options on the con-
trol panel (Fig. 9b)
60. Buttons for setting the mowing time and for
entering the PIN
61. "HOME" button
62. Locking button
63. "OK" button
64. "START" button
6.3 Cutting height adjustment facility
Important! Adjust the cutting height only when
the robot lawn mower has been switched off . Do
this by pressing the STOP button (3). The cutting
height adjustment facility (4) allows the cutting
height of the robot lawn mower to be set to infi ni-
tely adjustable settings between 20 and 60 mm,
which can be viewed on the scale.
If the grass is taller than 60 mm it has to be shor-
tened to a maximum of 60 mm fi rst to avoid expo-
sing the robot lawn mower to excessive load and
adversely aff ecting its operating effi ciency. Use a
conventional lawn mower or trimmer to do this.
After installation has been completed, the cutting
Anl_FREELEXO_Basic_SPK13.indb 40 Anl_FREELEXO_Basic_SPK13.indb 40
GB
height can be adjusted using the cutting height
adjustment facility (4). Always start with a higher
cutting height and reduce it in small steps until
you reach the desired height.
6.4 Locking mechanism / PIN
The locking mechanism prevents the unautho-
rized use of the robot lawn mower without a valid
code. You have to enter a personal four-digit secu-
rity code for this.
Lock release
- Before you start using the robot lawn mower,
you have to enter the correct PIN (standard
PIN: "1-2-3-4"). Open the display cover (23)
and press the locking button (62). Then enter
the PIN slowly in sequence and confi rm the
entry with the "OK" button (63). The control
functions will be unlocked and the lock LED
(51) will light up green.
- If you have entered an incorrect PIN, the lock
LED (51) will light up red. Press the locking
button (62) and re-enter the PIN.
Lock
If you want to lock the control panel (2), press the
locking button (62). The lock LED (51) will light
up red.
Standard PIN: New PIN:
1 2 3 4 _ _ _ _
Changing the PIN
To change the PIN, proceed as follows.
1. Unlock the control panel.
2. Press the "OK" button (63) and the "4H"
button (60) simultaneously and hold for 3
seconds. The time LEDs (50) will fl ash simul-
taneously.
3. Enter a new PIN (four digits). Press the "OK"
button (63).
4. Repeat step 3 to confi rm the new PIN.
5. Important! Make a note of your new PIN.
Requesting your PIN if you lose it
Have the receipt and the serial number of the
robot lawn mower ready. You need them in order
to get your PIN.
1. Connect an empty USB stick to the USB con-
nection (24) as shown (Fig. 11).
2. Switch on the main switch (7) (ON).
3. The robot lawn mower will automatically save
the PUK to your USB stick and will then end
the operation with a beep.
4. Pull out the USB stick. Import the data from
