Notice DIGI ® The material contained in this document is proprietary and for information only and is subjected to change without notice. Teraoka Weigh-System assumes no responsibility for any errors or damages arising from misinterpretation of any procedure. Screen displays, operating procedures and supporting features might vary with different software version releases.
Safety Information The operator of the equipment shall comply with the safety and warning indications and procedures outlined in this document. Teraoka Weigh-System Pte Ltd assumes no responsibility or liability for failure to comply with these requirements. For continued protection against fire hazard replace only with battery of same rating and type. Avoid overloading the product beyond its rated maximum capacity Trained and qualified personnel shall only carry out repair and servicing of product.
iii) Safety Regulations Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 6
This device is intended only for OEM integrators under the following conditions: 1) The transmitter module may not be co-located with any other transmitter or antenna. As long as conduction above is met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.).
802.15.4 standard. It implements a proprietary communications protocol based on the 802.15.4 standard streamlined to lower cost and power consumption. The TRK-RF-01 module design consists of the CC2420, the Atmel ATmega microcontroller (up to 16k internal flash), and integrated PCB trace antenna.
TRK-RF-01 User Manual Interface Interface pin assignments ( J1) LED ( Anode) LED (Cathode) / PortD.4 External Interrupt1 I/O1 ( PortD.7) I/O2 (PortC.1) I/O3 (PortC.0) I/O4 (PortD.1) I/O5 (PortD.0) Notes: 1) The I/O pins is connected to the controller – Atmega8L( /88V/16L/168V) ports directly. The functions of I/Os can be defined by user program.
