Timing With Program Swim Trainer; Prepare The Race; Start The Race - ALGE-Timing TIMY2 Manual

2

Timing with Program SWIM TRAINER

2.1 Prepare the race

•
Select the ID of the race by pressing the F0 button
•
Select the discipline
•
Select the number of touches
•
You are ready to start with C0 but first you should check the dead time and setting of
the edges of the channels:
o Make sure that the channels C1 to C4 are set sensitive to both edges:
MENU->CHANNELS->INTERNAL->EDGE
o You can set the delay time for the falling and rising edges for all channels.
Channel C0 has only a falling edge. The other channels have a falling and ris-
ing edge when you want to measure the start off time and turn time.
e.g.: MENU->CHANNELS->INTERNAL->DELAY->DELAY C1:
If you have set the rising and falling edge of this channel you can adjust two de-
lay times, one for each edge.

2.2 Start the race

•
With an impulse of C0 you start a race (e.g. from push button with Startbeep STB1 as
horn).
•
LINE of PRINTER: The printer shows the daytime of this event.
Now at the startblock, the competitor presses the socket (falling edge) ==> "reaction time" and
after a little time ==> "duration", the competitor jumps off the socket (rising edge) ==> "block-
offtime".
2. LINE of the PRINTER:
L1 SB+0.10 0.20 +0.30
blockofftime (= reactiontime+ duration)
duration
reaction time
Only times within +/- 2.5s are considered.
3. LINE of the PRINTER (if a second lane is used)
L2 SB-0.10 0.25 +0.15 In this example the reaction time is negative ==> blockofftime = -
0.10+0.25 = 0.15
Later some touchpad times may occur:
L1 TP 001 27.36 time from falling edge from the start until the falling edge of the touchpad
Duration 0.34 time from falling edge until rising edge of the touchpad. Also known as
turn-time
L1 TP 002 51.36
LAP 24.00 beginning from the second TP a LAP-time can be calculated
Duration 0.29
A started race can be reset by pressing th CLR button.
If you press the F3-button (ID/+1) the right index of ID (e.g. 123/13) is incremented for a new
race.
Manual
TIMY2 – SWIM TRAINER
C0 must be set to ARROW DOWN
C1 to C4 must be set to ARROW UP+ARROW DOWN
Page 7
