- Page 1 Version-E23-10-31 Manual PR1a Photocell Manual Page 1...
- Page 2 For further information or in case of problems that are mentioned not at all or not sufficiently detailed, please contact your ALGE -TIMING representative. You can find contact details on our homepage www.alge-timing.com Safety Apart from the information of this manual all general safety and accident prevention regulations of the legislator must be taken into account.
- Page 3 We declare that the following products comply with the requirements of the listed standards. ALGE -TIMING GmbH Rotkreuzstrasse 39 A-6890 Lustenau Declare under our sole responsibility, that the: Photocell PR1a is in conformity with the following standard(s) or other normative documents(s): Safety: EN 60950-1:2006 + A11:2009 EMC:...
- Page 4 Manual PR1a Page 4...
- Page 5 PR1a Contents General ......................... 6 Functionality ......................6 Photocell Features ....................6 Type of photocell ....................6 1.3.1 Reflection photocell PR1a-R: ......................7 1.3.2 Reflection photocell PR1a-RT:......................7 1.3.3 One-way photocell PR1a-d: ........................ 7 1.3.4 One-way photocell PR1a-dT: ......................7 Operating Modes ......................
- Page 6 Manual PR1a General The photocell PR1a combines highest precision and performance with smallest dimensions. 1.1 Functionality The photocell transmitter sends a modulated light beam in infrared range. The receiver moni- tors the light beam for disruptions. In case of a disruption of the infrared beam the receiver releases a pulse.
