Assembly Instructions
PNWD
Step
Code
A
Allen Key 4 mm dia.
Spring Washer 5/16" dia.
1
B
Flat Washer 5/16" dia.
Allen Bolt 5/16" x 2 1/2"
Spring Washer 5/16" dia.
2
B
Flat Washer 5/16" dia.
Allen Bolt 5/16" x 2 1/2"
Spring Washer 5/16" dia.
3
B
Flat Washer 5/16" dia.
Allen Bolt 5/16" x 2 1/2"
HARDWARE PACK LOCATION(S):
PNWD
COUNTER HEIGHT TABLE
D190-GT COUNTER HEIGHT TABLE
Hardware
PARTS LIST
Q'TY
1 Pc
8 Pcs
1. Table Top - 1 Pc
4 Pcs
2. Shelf - 2 Pcs
4 Pcs
3. Table Leg - 4 P cs
SKU # 43201906
SKU# 43201906
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ROOMS TO GO D190-GT
Summary of Contents for ROOMS TO GO D190-GT
- Page 1 Assembly Instructions PNWD D190-GT COUNTER HEIGHT TABLE SKU# 43201906 PARTS LIST Step Code Hardware Q’TY Allen Key 4 mm dia. 1 Pc Spring Washer 5/16” dia. 8 Pcs Flat Washer 5/16” dia. 1. Table Top - 1 Pc Allen Bolt 5/16” x 2 1/2”...
- Page 2 Assembly Instructions PNWD D190-GT COUNTER HEIGHT TABLE SKU# 43201906 ***Cautions: Please read all instructions carefully before starting the assembly process. These parts are cumbersome and heavy. Therefore, two people are recommended in order to prevent personal injury and insure the parts are not damaged during the assembly.
