Delta-q IC650 Product Manual

Charger Error Codes
Code Description Solution
E-0-0-1 Battery high Check the battery voltage and cable connections. Check battery
E-0-4-7 voltage size and condition. This error will clear once the condition has
been corrected.
E-0-0-4 BMS or battery Refer to unit's operator manual.
fault detected
E-0-0-7 Battery amp hour Possible causes include poor battery health, very deeply
limit exceeded discharged battery, poorly connected battery, and / or high
parasitic loads on battery while charging. Possible solutions:
Replace battery pack. Check DC connections. Disconnect parasitic
loads. This error will clear once the charger is reset by cycling DC.
E-0-1-2 Reverse polarity Battery is connected to the charger incorrectly. Check the battery
error connections. This error will clear once the condition has been
corrected.
E-0-3-7 Re-programming Software upgrade failure or script operation failure. Check new
failed software is correct.
E-0-2-3 High AC voltage Connect charger to an AC source that provides stable AC between
error (>270VAC) 85 - 270 VAC / 45-65 Hz. This error will clear once the condition has
been corrected.
E-0-2-4 Charger failed to The charger has failed to turn on properly. Disconnect AC input
initialize and battery for 30 seconds before retrying.
E-0-2-5 Low AC voltage AC source is unstable. Could be caused by undersized generator
oscillation error and /or severely undersized input cables. Connect charger to an AC
source that provides stable AC between 85 - 270 VAC / 45-65 Hz.
This error will clear once the condition has been corrected.
E-0-2-9 Communication Check continuity of signal wires to Battery. Check compatible
E-0-3-2 Error with Battery Battery installed. Check charger software is correct.
E-0-4-6
E-0-6-0
E-0-6-1 Current Mismatch Refer to unit's operator manual.
E-0-6-2 Voltage Mismatch Refer to unit's operator manual.
Delta-Q 650
IC
650W Industrial Battery Charger for Lithium
650W Industrial Battery Charger
Product Manual - Important Safety Instructions - Original Instructions
Please save this manual as it contains important safety and operating instructions for
the Delta-Q IC650 Industrial Battery Charger. Please read this information in its entirety
before using your Delta-Q IC650 Charger. For technical support, please contact the
manufacturer of your vehicle or machine, as their version of this charger may require
special instructions.
WARNING
Use charger only with an algorithm that is appropriate to the specific battery type
and capacity. Other usage may cause personal injury and damage. Keep sparks, flames,
and smoking materials away from batteries. If this charger is used with lithium-ion
type batteries, an integrated battery management system (BMS) must be used. The
BMS must ensure that in all operating modes, the battery cells are protected from
inappropriate levels of voltage, current, temperature, and state of charge. Do not
operate charger in a closed-in area or restrict ventilation. Never charge a frozen or
non-rechargeable battery. Observe all battery manufacturers' precautions.
DANGER
Risk of electric shock. Connect charger power cord to an AC outlet that has been
properly installed and grounded in accordance with all local codes and ordinances. A
grounded AC outlet is required to reduce the risk of electric shock—do not use ground
adapters or modify the plug. Do not touch uninsulated portions of the output connector
or uninsulated battery terminals. Disconnect the AC supply before making or breaking
the connections to the battery. Do not open or disassemble the charger. Do not operate
this charger if the AC supply cord or DC output cord is damaged or if the charger has
received a sharp blow, been dropped, or is damaged in any way. Refer all repair work
to the manufacturer, or qualified personnel. This charger is not intended for use by
persons (including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge on electrical systems and battery charging, unless
they have been given supervision or instruction concerning use of the charger by a
person responsible for their safety. Children should be supervised to ensure they do
not play with the charger.
© 2018 Delta-Q Technologies Corp. All rights reserved. (PN: 710-0230 Rev 2 Date: 13/03/2018)
