THORLABS EXULUS-4K1 Instructions Manual page 5

Average Reflectance
a
Phase / Retardance Range
b
Angle of Incidence
Optic Axis
Reflected Wavefront Distortion
Frame Rate
c
Optical Power Handling
Pulsed (ns)
Damage Threshold
Pulsed (fs)
d
Fluctuation / Flickering (RMS)
Beam Deviation Using Panel Tip /
Tilt
e
Trigger Output
Trigger Output High Voltage
Level
Trigger Output Pulse Width
Connector Type (for Tubing)
Tubing Dimensions
Dimensions (L x W x H)
Weight
Storage Temperature
e
Operating Temperature
PC Connection
Bit Depth
SLM Head Thermistor
Type
Accuracy
a. Phase/retardance range values are for 30 °C when used with the LK220 liquid chiller.
b. Other angles of incidence will result in phase shifts that differ from the programmed pattern. Angles of
up to 10° are possible without significantly affecting performance.
c. Specification with the LK220 Liquid Chiller
d. Fluctuation / Flickering is the phase fluctuation as the percentage of the entire phase range and is
dependent on current phase setting. The value stated is the maximum fluctuation and typically occurs at
half of the phase range.
e. For more details on the external trigger output, please refer to the product manuals accessible through
the red Docs ( ) icons below.
f. Ambient temperature fluctuations may cause the characteristics of your SLM to change. Using it at an
ambient temperature of 25 °C is recommended.
Item #
Panel Resolution
Type
Operating Wavelength
Panel Active Area
80% (Typical)
2π at 633 nm (Full Wave Mode)
π at 633 nm (Half Wave Mode)
<λ/2 @ 633 nm
≤200 W/cm
2
0.22 J/cm
(532 nm, 6.8 ns, 10 Hz, Ø200.5 µm)
2
0.0935 J/cm
(515 nm, 203.3 ns, 100 Hz, Ø108.2
µm)
<0.01%
SMA Female
5 V (TTL)
®
CPC Valved Thumb Latch Quick-Disconnect Fitting
0.17" (4.3 mm) Inner Diameter (Pre-Installed)
0.24" (6 mm) Inner Diameter (Optional)
220.0 mm x 104.0 mm x 68.0 mm (8.66" x 4.09" x 2.68") All-in-One Mode
420.0 mm x 104.0 mm x 42.0 mm (16.54" x 4.09" x 1.65") Separate-
Panel Mode
0.7 kg (1.54 lbs)
0 °C to 60 °C (32 °F to 140 °F)
10 °C to 40 °C (50 °F to 104 °F)
HDMI-Compatible Connector
USB 2.0 Connector
8 Bit, 0 - 255 Gray Level
VISHAY NTC LE413 (R = 10 kΩ @ T
0
±0.5 °C (@ 25 °C)
EXULUS-4K1(/M)
3840 x 2160 (4K UHD)
Liquid Crystal on Silicon (LCoS) with Reflective Coating
15.6 mm x 9.2 mm
2π at 1064 nm (Full Wave Mode)
π at 1064 nm (Half Wave Mode)
0°
0°
<0.4λ @ 633 nm
60 Hz
2
0.15 J/cm
(1064 nm, 10 ns, 100 Hz, Ø235
µm)
2
0.03 J/cm
(1030 nm, 200 fs, 100 Hz, Ø135
µm)
<0.15%
N/A
54 µs
= 25 °C, B = 3435 K)
0
400 - 850 nm
